- Page 1 FXxQ0xx Pressure sensors with temperature measurement and IO-Link Operating Instructions Translation of the Original Operating Instruction Subject to change without notice Available as PDF version only Version: 1.0.0 Status: 29.04.2019 www.wenglor.com...
-
Page 2: Table Of Contents
Table of Contents General ..............................4 Information Concerning these Instructions ..................4 Explanations of Symbols ........................4 Limitation of Liability ..........................5 Copyrights ............................. 6 For Your Safety ............................6 Use for Intended Purpose ........................6 Use for Other than the Intended Purpose..................... 7 Personnel Qualifications ........................ - Page 3 Settings ..............................23 IO-Link ..............................24 Maintenance Instructions ........................24 10. Returns ..............................24 11. Proper Disposal .............................24 12. Appendix ..............................25 12.1 List of Abbreviations ..........................25 12.2 Change Index, Operating Instructions ....................25 12.3 EU Declaration of Conformity ......................25 Pressure sensors with temperature measurement and IO-Link...
-
Page 4: General
• Local accident prevention regulations and national work safety regulations must be complied with as well. • The product is subject to further technical development, and thus the information contained in these oper- ating instructions may also be subject to change. The current version can be found at www.wenglor.com in the product’s separate download area. -
Page 5: Limitation Of Liability
• wenglor assumes no liability for printing errors or other inaccuracies contained in these operating instruc- tions, unless wenglor was verifiably aware of such errors at the point in time at which the operating instruc- tions were prepared. -
Page 6: Copyrights
• All rights are reserved by wenglor. • Commercial reproduction or any other commercial use of the provided content and information, in particu- lar graphics and images, is not permitted without previous written consent from wenglor. 2. For Your Safety 2.1 Use for Intended Purpose... -
Page 7: Use For Other Than The Intended Purpose
• The product is not suitable for use in potentially explosive atmospheres. • The product may only be used with accessories supplied or approved by wenglor, or in combination with approved products. A list of approved accessories and combination products can be accessed at www.wenglor.com on the product detail page. -
Page 8: General Safety Precautions
• In the event of possible changes, the respectively current version of the operating instruc- tions can be accessed at www.wenglor.com in the product’s separate download area. • Read the operating instructions carefully before using the product. -
Page 9: Technical Data
3. Technical Data Order Number FXxQ0xx Technical Data Sensor-Specific Data Measuring range –1 ... 10 bar, in various pressure stages Pressure type relative Media temperature See technical data sheet Measuring range Temperature See technical data sheet Measurement error (incl. hysteresis, linearity, repetition <... - Page 10 Configurable as PNP, NPN or push-pull Switching output switchable to current or voltage Switchable to NC or NO * Tested by wenglor The following table specifies the tightening torques of the connector plugs and mounting options in order to assure compliant, error-free operation:...
-
Page 11: Housing Dimensions
3.1 Housing Dimensions G3/4" Pressure sensors with temperature measurement and IO-Link... -
Page 12: Wiring Diagram
3.2 Wiring Diagram Technical Data... -
Page 13: Accessory Products
3.3 Accessory Products wenglor can provide you with suitable connection technology for your product. Suitable mounting technology no. G3/4": Suitable connection technology no. IO-Link master ZAI72AN01, EFBL001, EFBL003 3.4 Layout = plug connector = process connection 3.5 Scope of Delivery •... -
Page 14: Transport And Storage
4. Transport and Storage 4.1 Transport Upon receipt of shipment, inspect the goods for damage in transit. In the case of damage, conditionally accept the package and notify the manufacturer of the damage. Then return the device, making reference to damage in transit. -
Page 15: Installation And Electrical Connection
5. Installation and Electrical Connection 5.1 System Overview Connector Cables ZCCL001 (straight, PVC, IP69K) 10 m S23-2M (straight, PVC) 2 m S23-2MPUR (straight, PUR) 2 m S23-5M (straight, PVC) 5 m S23-5MPUR (straight, PUR) 5 m S23-10M (straight, PVC) 10 m S23-10MPUR (straight, PUR) 10 m S29-2M (angled, PVC) 2 m S29-5M (angled, PVC) 5 m... -
Page 16: Installation
5.2 Installation • Protect the product from contamination during installation. • Observe all applicable electrical and mechanical regulations, standards, and safety rules. • Protect the product against mechanical influences. • Make sure that the sensor is mounted in a mechanically secure fashion. •... -
Page 17: Diagnostics
NOTE! • Shut down the machine. • If the error cannot be eliminated, please contact wenglor’s support department. • Do not operate in case of indeterminate malfunctioning. • The machine must be shut down if the error cannot be unequivocally clarified or reliably eliminated. -
Page 18: Functions Overview
Final value, analog output 100 % of the MUL 6.2 Function Definitions • All functions are configured via the IO-Link interface. • Refer to the interface protocol concerning parameters configuration (available at www.wenglor.com on the product detail page). Designation Function... -
Page 19: Hysteresis
6.2.1 Hysteresis • Depending on the settings selected for switching points 1 and 2, the sensor’s switching performance can be adjusted to the application. Switching Output Hysteresis Rising Characteristic Curve Falling Characteristic Curve Pression + Temperature Switching Point 2 Switching Point 1 6.2.2 Window Width •... -
Page 20: Analog Value Scaling
6.2.3 Analog value scaling • Allocation of the analog starting point of 4 mA/0 V and the analog end point of 20 mA/10 V to the measur- ing range is freely selectable. Voltage/Current Overall Measuring Range Non-Inverted 10 V, 20 mA Output Function Inverted Output Function... - Page 21 Wiring OPT70S Remote Switching Output, e.g. Indicator Lamp Remote Analog Output e.g. Proportional Valve Figure 1: Wiring With Remote Output Function External comp. (e.g...) Lamp/Valve IO-Link E (analog/digital) – – Figure 2: Wiring Remote Analog Output e.g. Proportional Valve Figure 3: Wiring Without Remote Output Function Pressure sensors with temperature measurement and IO-Link...
-
Page 22: Filter
FXxQ0xx Connection cable, e.g. EFBL003 master with PC with free software BG2SG2V1-2M USB cable wTeach (DNNF005) Figure 4: Cables when using wTeach 6.2.5 Filter • The filter represents the number of values used by the sensor to generate a mean value for pressure mea- surement. -
Page 23: Settings
7. Settings Parameters adjustable via the IO-Link interface: Sensor Settings Pressure unit of measure bar/mbar (depending on the measured value) Temperature unit of measure Celsius Fahrenheit Switching output function Push-pull Analog output function 4…20 mA 0…10 V Analog output scaling Initial and final values between 0 and 100 % of the measured value Function, output 1... -
Page 24: Io-Link
• Deposits upstream from the pressure measuring cell may influence results. 10. Returns Due to legal regulations and for the protection of employees, wenglor sensoric GmbH requires a signed declaration of decontamination before your order can be processed. The corresponding form is available at www.wenglor.com Download General Terms and Conditions and Returns. -
Page 25: Appendix
Description/Change 1.0.0 29.04.2019 Initial version of the operating instructions 12.3 EU Declaration of Conformity The EU declaration of conformity can be found on our website at www.wenglor.com in the product’s separate download area. Pressure sensors with temperature measurement and IO-Link...
