20.3 Accessing the Instrument from a PC (FTP
Server)
This section explains the following settings for accessing the instrument from a PC on a network:
Items Common to Scope Mode and Recorder Mode
• User name
• Password
• Timeout
• Starting an FTP client
UTILITY Network Menu
1.
On the waveform screen's MENU, tap OTHERS > UTILITY, or press UTILITY.
2.
Tap Network, or press the soft key. The following screen appears.
Configuring the FTP Server (FTP/Web Server)
3.
Tap FTP/Web Server, or press the soft key. The following screen appears.
Note
If you set the user name to "anonymous," you can connect to the instrument without entering a password.
Starting an FTP Client
Start an FTP client on a PC. Enter the user name and password that you have set on the
instrument's FTP/Web Server screen shown above, and connect to the instrument.
IM DL950-02EN
► "FTP Server (FTP/Web Server)" in the Features Guide
Select Network.
Configure the TCP/IP settings
► sec. 20.2 (/C60 option)
Configure the TCP/IP settings
► sec. 20.2
See "Configuring the FTP Server."
(For information on the Web server, see
section 20.4.)
Configure mail settings. ► sec. 20.6
Configure network printing. ► sec. 20.8
Configure the network drive. ► sec. 20.5
Configure SNTP. ► sec. 20.7
Set the user name (up to 15 characters).
Set the password (up to 15 characters).
Set the timeout (30 to 3600).
Selects 1G or 10G (displayed for the /C60 option)
Applies the settings
20-7
