- Page 1 OPERATING AND INSTALLATION INSTRUCTIONS SCAN-LINE 805 AQUA Approved for use in smoke control areas when burning dry wood logs or authorised fuels www.heta.dk DANISH DESIGN . DANISH QUALITY . DANISH PRODUCTION...
- Page 2 Heta stove. Especially if you follow the following advice and instructions. Scan-Line 805 Aqua is approved according to EN 13240, 15 a B-VG, NS 3058/3059 og AEA (De- fra). These approvals, means that the wood stove insert meets a variety of specifications and re- quirements, ensuring it is made of quality materials, minimum environmental impact and that it has an optimum fuel economy.
-
Page 3: Installation Instructions
INSTALLATION INSTRUCTIONS The chimney connection Safety clearances The chimney opening must follow national and Stoves must always be installed in line with nati- onal and, if applicable, local regulations. It is im- local regulations. However, the area of the ope- ning should never be less than 175 cm , which portant to abide by local regulations regarding... -
Page 4: First Firing
chimney and the low temperature of the fresh • The chimney contains false air. air. The length and insulation of the chimney, • The chimney and flue gas pipe are blocked. wind and weather conditions also have an effect • The house is too airtight (i.e. when there is on the ability of the chimney to generate appro- an insufficient supply of fresh air). -
Page 5: Chimney Fires
1.3 kg CO every time you have used 1 kg nor- mal wood. Chimney fires In the event of a chimney fire – which often re- sults from incorrect operation or protracted fi- ring with moist wood – close the door and shut off the secondary/start-up air supply to smother the fire. -
Page 6: Reduced Burning
Reduced burning stove, and the viewing window and other parts will become covered with soot. If this situation is The stove is well suited to intermittent use. If combined with firing with wet wood, the build-up you wish to operate the stove with reduced out- of soot can become so thick and sticky that the put, simply insert smaller volumes of wood at sealing rope can, for example, become detached... -
Page 7: Maintenance
The Heta SL805 requires a permanent air vent opening of minimum 550 sq mm under Building Cleaning the glass Regulations if the stove is not going to be fitted to an external outside fresh air supply. - Page 8 Connection of external air flow (fresh air) through the floor on Scan-Line 805 Aqua When connection external air flow use a ø100 air conduit (for instance Lindab) with match- ing collar band. The stove is prepared for a fresh air intake.
- Page 9 It is very important that the plates between the cooling pipes lies as assembled on the picture (as when you receive it from Heta), otherwise it will result in great loss of efficiency and raise the temperature of the chimney.
- Page 10 Cleaning after sweeping the chimney and replacing the stones. Scan-Line 805 Aqua...
- Page 11 - boiling safety fuse (point 2) Scan-Line 805 Aqua is delivered from Heta so 600 litres per hour. This could be checked by that it can be fitted on an existing system with seeing if you can fill a 10 litres bucket on 1 matching circulating pump and safety valve.
