- Page 1 OPERATING AND INSTALLATION INSTRUCTIONS ICON-LINE ECLIPSE SERIES Icon-Line Eclipse SCA is exempt for use in smoke control areas when burning dry wood PENDING www.heta.dk DANISH DESIGN . DANISH QUALITY . DANISH PRODUCTION...
-
Page 2: Table Of Contents
Icon-Line Eclipse series have been approved according to the EN 13240, NS 3058, NS 3059. And the Icon-Line Eclipse series are modified so that they are also re- commended as exempt for use within smoke control areas (SCA) throughout the UK (see clean air act Appendix A) of the air supply regulation so that it can`t be closed completely. -
Page 3: Before Installation
It is important that upon receipt check your Heta product completely and report any damage or defects to your dealer. The packaging must be disposed of as follows: Wood is untreated and able to burn in the stove. - Page 4 With your new wood stove you should find the following: Operating / Q.C. check Instruction manual Heta glove Graphite spray for lubrication Nr. 0023-9002 Nr. 0027-0130 Data plate Handle 6000-027805 8057 0000-DK Heta A/S Jupitervej 22 . DK-7620 Lemvig . Denmark EN 13240:2001/A2:2004 - AEA - NS 3058/3059, Aus §15A...
-
Page 5: Operating Instructions
1. OPERATING INSTRUCTIONS 1.1 Before using Icon-Line Eclipse SCA series stoves are desig- ned and tested to burn extremely cleanly with Before the wood stove is used make sure required very little smoke discharge and are exempt for installation conditions, are met. See page use in smoke control areas throughout the UK when burning dry wood logs. -
Page 6: Refueling
sition. This ensures the stove and chimney are When refueling be careful to place the fuel into the combustion cham- thoroughly heated. ber gently, (use the provided glove). By not doing so you risk cracking or Startup/Lighting breaking the vermiculite. Scan the code and select a language. -
Page 7: Draft Conditions In The Chimney
(In excess of 90° C). Nominal fluegas temperature: 282° Children should avoid contact with the stove. Icon-Line Eclipse Series, relative to 20°C. Setting up a fence if you have small children may Flue gas flow is: 4.5 g/sec. -
Page 8: Fuel
1.10 Fuel about 5.27 kW/hour for absolute dry wood. Wood with a moistness of 18% has a efficiency Your new stove is EN approved for firing with of about 4.18 kW / hour per kg, and one litre wood fuel. You must therefore only burn clean, heating oil contains about 10 kW / hour. -
Page 9: Cleaning The Glass
1.14 Cleaning the glass resistant paint. The stove should be cleaned with a damp cloth. Incorrect firing, for example using wet wood, Any damage to the surface in the form of chips can result in the viewing window becoming co- or scratches can be repaired using touch-up vered in soot. -
Page 10: Troubleshooting
1.17 Troubleshooting table - applies to all stove types Fault Cause Troubleshooting Solution Inadequate chimney draft. Lighting problems. When the You can test using a lighter whether Improve the chimney. The chimney only has stove is cold, smoke seeps flame is drawn into the combustion sufficient draft when it is hot. - Page 11 Therefore, the duration of the warranty is 5 years on this product, covering manufactu- rer’s defects, 1 year on paint adhesion defects from purchase date from Heta and a 3 months total warranty for seals, vermiculite and glass from the date of sale from the dealer.
- Page 12 1.20 Icon-Line Eclipse Series. Cleaning after sweeping or before replacing vermiculite stones Note: it may be necessary to clean/vaccum the holes and air ducts behind the rear stone. Order of removing Fire bricks. Replace in reverse order. Starting with Fig. 6.
- Page 13 1.21 Icon-Line Eclipse Series Side windows Cleaning after sweeping or before replacing vermiculite stones Note: it may be necessary to clean/vaccum the holes and air ducts behind the rear stone. Order of removing Fire bricks. Replace in reverse order. Starting with Fig. 6.
- Page 14 1.22 Icon-Line Eclipse Series Parts - Inside fire chamber Pos. Name Qty. 1 0023-026238 Vermiculite right side - front 2 0023-026705 Bottom stone - left side 3 0023-026706 Bottom stone - right side 4 0023-026708 Vermiculite, rear, right 5 0023-026972...
- Page 15 Icon-Line Eclipse Series Side windows Parts - Inside fire chamber Pos. Name Qty. 1 0023-026705 Bottom stone - left side 2 0023-026706 Bottom stone - right side 3 0023-026708 Vermiculite, rear, right 4 0023-026709 Vermiculite right side - front 5 0023-026877...
- Page 16 Parts - Door Pos. Name Qty. 1 0008-0014 M6x6 Hexagon socket head cap screw BN 1206 Black 2 0008-1002 M6x6 Hexagon socket set screw BN30, FZB 3 0008-2304 M4x6 Hexalobular socket pan head screw BN 5687, RF A2 4 0008-3503 M6/12x1,6 Washer BN 560, Brass 5 0008-9082 6x35 Round head rivet BN 988...
- Page 17 Installation Instructions Contents Installation instructions ..............18 Distance requirements ..............18 Floor ....................18 Chimney connection ................. 18 Combustion air and ventilation ............19 Stovedrawings/measurments ............. 19-20 Connecting direct air below or behind ..........21 Clearances for installation EN 13 240 ..........22 Changing to a back flue outlet ............
-
Page 18: Installation Instructions
flue gas pipe ve or on page 11 of this manual. must be sealed with fireproof material and / or beading. Heta A/S stresses that it is of utmost 2.2 Floor importance that this is done correctly with very tight joints. -
Page 19: Combustion Air And Ventilation
5 kW. combustion air in the inset stove comes from The Icon-Line Eclipse series have a nominal the room in which it is fitted. However, by con- output of less than 6,6 kW and does not need necting a sealed air inlet to the stove’s air intake... - Page 20 Icon-Line Eclipse Side windows ø100 115 Center fresh air from bottom...
-
Page 21: Connecting Direct Air Below Or Behind
ø100 mm, the draught in the flue depends on this air for optimal combu- stion. Heta recommends max. 4 meters of direct air pipe, with max. 3, 90° bends and a min. of ø100 Flexi-pipe to the floor... -
Page 22: Clearances For Installation En 13 240
2.7 Clearances for installation EN 13 240 Combustible material - Non-flammable substrate Furnitures The dimensions are the minimum dimensions, unless otherwise stated. Clearances Oventype Distance from oven to combustible material Stove Rear the At the Over Corner Minimum stove side oven furnitures distance... -
Page 23: Changing To A Back Flue Outlet
2.8 Changing to a back outlet Accessory 0030-2410... -
Page 24: Installation Of Purchased Bottom Door
2.9 Installation of purchased bottom door Bottom door Nr. 6000-027195... - Page 25 3. Appendix A The Clean Air Act 1993 and Smoke Control Areas. Under the Clean Air Act local authorities may gulatory Reform (Scotland) Act 2014. In Wales declare the whole or part of the district of the and Northern Ireland these are authorized by authority to be a smoke control area.
-
Page 27: Eu Declaration Of Conformity
Certifikat no. 2631 Manufacturer Heta A/S Ecodesign Adress Jupitervej 22, DK 7620 Lemvig EU Declaration of Conformity E-mail heta@heta.dk Website www.heta.dk DoC Icon-Line Eclipse Side windows 2631-2022 Telephone +45 9663 0600 Product fiche Model identifier Icon-Line Eclipse, Icon-Line Eclipse Side windows The identified product described above is in...
