SEMI-SCALE ARF EP/GLOW R/C MODEL AIRPLANE
I
N
S
T
I
N
S
T
Shown with optional motor, propeller,
dummy engine and pilot figures.
The Taube ("dove" in German) was the first military airplane mass-produced in Germany. Designed in
1909 by Ignaz "Igo" Etrich of Austria-Hungary and first flown in 1910, wires supported and controlled
warping of the wing tips, and the horizontal stabilizer's trailing edge could also be warped up and down.
On November 1, 1911, the world's first aerial bomb was dropped from a Taube by Italian aviator Giulio
Gavotti. German pilots flying a Taube spotted the advancing Imperial Russian Army at the start of the Battle
of Tannenberg between Germany and Russia.
We are pleased to acknowledge and
thank Robert A. Lippman for encouraging us
to develop and introduce this semi-scale
model of a Rumpler factory-produced Taube.
This is the first and only radio-controlled
ARF model with functional wing and tail
warping. Built to about 1/9
pre-installed control cables and a pilot's
control stick that moves the elevator. It also
includes scale-looking articulated landing
gear and a spring-loaded tail skid. It is
constructed mainly of balsa, plywood and composite materials. Assembly is surprisingly easy for such a
full-featured model. A dummy engine, vintage-style spoked wheels and pilot figures are available as
optional upgrades.
We invite you to enjoy the pride of ownership and the joy of flying this beautiful ARF
semi-scale model
of the famous
Rumpler Taube
.
TABLE OF CONTENTS:
I.
Important safety precautions ............................ 2
II.
Preflight checks ................................................ 4
IV. Specifications ................................................... 5
Copyright 2015 by Maxford USA
P
L
E
P
L
E
R
U
C
T
R
U
C
T
scale, it has
th
R
T
R
T
I
O
N
M
I
O
N
M
V.
Parts List .............................................
VI.
VII.
Assembly instructions ............................
1
Page
A
U
B
A
U
B
A
N
U
A
A
N
U
A
RUMPLER TAUBE / Doc. Nbr. S160113
E
E
L
L
5
5
6
Advertisement
Related Manuals for Maxford USA RUMPLER TAUBE
Summary of Contents for Maxford USA RUMPLER TAUBE
-
Page 1: Table Of Contents
Preflight checks ……………………………………..4 Special features …………......III. Warranty, liability waiver & return policy …. 4 VII. Assembly instructions ..…....... IV. Specifications ..………………………………..... 5 VIII. Setup & adjustments ......... 16 Copyright 2015 by Maxford USA Page RUMPLER TAUBE / Doc. Nbr. S160113... -
Page 2: Important Safety Precautions
Because of its performance capabilities, this product, if not assembled and operated correctly, could cause injury to you or spectators and damage to property. Maxford USA provides you with a high-quality, thoroughly tested model airplane kit with assembly instructions. - Page 3 Determine which way the control surface must be twisted to correct the warp/twist. Copyright 2015 by Maxford USA Page RUMPLER TAUBE / Doc. Nbr. S160113...
-
Page 4: Preflight Checks ................................................ 4 Vi. Special Features
III. LIMITED WARRANTY, LIABILITY WAIVER & RETURN POLICY Maxford USA guarantees this kit to be free from defects in material and workmanship at the time of purchase. Our products have been inspected in our factory and are checked again when shipped from our warehouse. -
Page 5: Parts List
3. Returned merchandise that is accepted by Maxford USA for credit is subject to a 10% to 20% restocking fee (the final amount will be determined by Maxford USA upon receipt and examination of the returned merchandise). Return address: Maxford USA... -
Page 6: Assembly Instructions
(NOTE: This ARF comes with wooden wheels. Learn about Maxford USA vintage-style spoked wheels at http://www.maxfordusa.com/vintagestyle3spokedwheels.aspx.) Maxford USA scale pilot figures (shown at far right). Servo extension safety clips. Firewall for optional glow-engine setup. VII. ASSEMBLY INSTRUCTIONS A. - Page 7 Copyright 2015 by Maxford USA Page RUMPLER TAUBE / Doc. Nbr. S160113...
- Page 8 13. Slide a crimp tube onto the cable. Guide the cable through the swivel at the bottom of the vertical stabilizer, then back through the crimp tube. 14. Secure the cable and swivel with masking tape. Copyright 2015 by Maxford USA Page RUMPLER TAUBE / Doc. Nbr. S160113...
- Page 9 Attach the clevis to the horn at the lower end of the pilot’s control stick. 24. Pull the cable through the fuselage with coat-hanger wire as pictured below. Copyright 2015 by Maxford USA Page RUMPLER TAUBE / Doc. Nbr. S160113...
- Page 10 30. Install the rudder’s pull-pull cables as pictured below. Point swivels toward the horizontal stabilizer and secure with epoxy. Crimp tube Crimp tube Copyright 2015 by Maxford USA Page RUMPLER TAUBE / Doc. Nbr. S160113...
- Page 11 3. Connect a 12-inch extension to each wing- warping servo. (NOTE: As mentioned on page 2 in #9, optional Maxford USA servo- extension safety clips are recommended.) 4. Guide the extensions’ servo-like connectors from each servo bay out through the root rib of each wing panel as detailed in #13 on page 3.
- Page 12 -inches (10.8 cm) behind the leading edge of the wing. Set the CG at approx. - to 4 -inches (8.3 to 10.8 cm) behind the wing’s leading edge. Copyright 2015 by Maxford USA Page RUMPLER TAUBE / Doc. Nbr. S160113...
- Page 13 7. Glue a wood block at each side of the nose. 8. Drive wood screws through the cowl and into the wood blocks to secure the cowl to the nose. Copyright 2015 by Maxford USA Page RUMPLER TAUBE / Doc. Nbr. S160113...
- Page 14 Top-side wing wires and swivels attached with 2 springs, 2 swivels 1 bolt and 1 nut. Copyright 2015 by Maxford USA Page RUMPLER TAUBE / Doc. Nbr. S160113...
- Page 15 Test-fit the pilot mounting platforms (shown at the right) onto the cockpit hatches and secure the platforms with glue. b. Position and glue -scale pilot figures onto their platforms. Copyright 2015 by Maxford USA Page RUMPLER TAUBE / Doc. Nbr. S160113...
- Page 16 VIII. SETUP & ADJUSTMENTS Even though this ARF may be capable of more aerobatic performance, we recommend that it looks best when flown in a scale-like manner, like the original Rumpler Taube, with flat, gentle turns. 1. Center of gravity (CG): NOTE: This brace is approx.
- Page 17 Toll free (orders only) ....(866) 706-8288 www.maxfordusa.com Website ......Order replacement parts, optional accessories, servos, brushless motors, electronic speed controls, and a wide variety of other high-quality RC hobby items online at www.maxfordusa.com. Copyright 2015 by Maxford USA Page RUMPLER TAUBE / Doc. Nbr. S160113...
