DEMO MANUAL DC1705C

PARTS LIST

ITEM QTY
DC1705C GENERAL BOM
1 4
2 2
3 8
4 2
5 4
6 1
7 1
8 2
9 1
10 1
11 1
12 4
13 1
14 4
15 2
16 1
17 1
18 1
19 4
20 3
21 4
22 1
23 2
24 1
25 1
26 1
27 4
28 2
DC1705C-A
1 1
2 1
3 1
4 1
5 1
6 1
8
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
REFERENCE
C1, C8, C9, C18
C2, C10
C3, C13, C17, C22, C23, C24, C25, C26
C6, C11
C7, C12, C15, C19
C14
C16
C20, C21
D1
E3
JP1
J1, J3, J4, J5
J2
J6, J7, J8, J9
L1, L2
R1
R3
R4
R5, R6, R7, R13
R8, R9, R14
R10, R11, R12, R16
R15
U2, U3
U4
U5
SHUNT ON JP1 (2&3)
MH1-MH4
CI1
CI2
CP
RZ
U1
PART DESCRIPTION
CAP ., X7R, 1.0μF , 16V, 10%, 0805
CAP ., TANTALUM, 330μF , 10V, 10%, 7343
CAP ., X5R, 0.1μF , 10V, 10%, 0402
CAP ., X5R, 1.0µF , 16V, 10%, 0402
CAP ., X7R, 0.01μF , 16V, 10%, 0402
CAP ., X7R 0.022μF 16V 10%, 0402
CAP ., X7R, 2.2μF , 16V, 10%, 0805
CAP ., NPO, 100pF , 50V, 5%, 0402
LED, RED
TURRET, TESTPOINT, 2501
HEADERS, 3 PINS 2mm CTRS.
CON., SMA 50Ω EDGE-LANCH
CON., HEADER, 14 PIN, 2mm
JACK, BANANA
IND, 68nH 5%, 0402
RES., CHIP , 51.1Ω, 1/16W, 1%, 0402
RES., CHIP , 330Ω, 1/16W, 1%, 0402
RES., CHIP , 15Ω, 1/16W, 1%, 0402
RES., CHIP , 200k, 1/16W, 1%, 0402
RES., CHIP , 4.99k, 1/16W, 1%, 0402
RES., CHIP , 100Ω 1/16W, 5%, 0402
RES., CHIP , 0Ω, 0603
I.C., DUAL BUFFER, SC70
I.C., DUAL TRANSCEIVER, SOT363
I.C., SERIAL EEPROM, TSSOP8
SHUNT, 2mm CTRS.
STANDOFF , NYLON, 0.5, 1/2"
STENCILS (TOP & BOTTOM)
GENERAL BOM
CAP ., X7R 0.022μF 50V 5% 0603
CAP ., COG 6800pF 50V 5% 0805
CAP ., COG 2700pF 50V 5% 0603
RES., CHIP , 453Ω, 1/10W 1%, 0603
I.C. SYNTHESIZER, QFN28UFD-4X5
MANUFACTURER/PART NUMBER
TDK, C2012X7R1C105K
AVX, TPME337K010R0035
TDK, C1005X5R1A104K
TDK, C1005X5R1C105K
AVX, 0402YC103KAT2A
AVX 0402YC223KAT2A
TDK, C2012X7R1C225K
TDK, C1005C0G1H101J
ROHM, SML-010VTT86L
MILL-MAX, 2501-2-00-80-00-00-07-0
SAMTEC TMM-103-02-L-S
E.F . JOHNSON, 142-0701-851
MOLEX, 87831-1420
KEYSTONE, 575-4
COILCRAFT, 0402HPH-68NXJLW
NIC, NRC04F51R1TRF
NIC, NRC04F3300TRF
NIC, NRC04F15R0TRF
NIC, NRC04F2003TRF
NIC, NRC04F4991TRF
NIC, NRC04J101TRF
VISHAY, CRCW06030000Z0EA
FAIRCHILD SEMI., NC7WZ17P6X
NXP , 74LVC1T45GW
MICROCHIP , 24LC025-I /ST
SAMTEC 2SN-BK-G
KEYSTONE, 8833 (SNAP ON)
DC1705C-1
AVX 06035C223JAT2A
MURATA GRM2195C1H682JA01D
MURATA GRM1885C1H272JA01D
NIC, NRC06F4530TRF
LINEAR TECH., LTC6946IUFD-1
