DESCRIPTION
Demonstration circuit 1774A-C features the LTC
gain block amplifier. The LTC6431-15 has a power gain of
15.5dB and it is part of the LTC643X-YY amplifier series.
DC1774A-C is part of the DC1774A demo boards fam-
ily supporting the LTC643X-YY family. The demo board
DC1774A-C is optimized for a frequency range from
100MHz to 1200MHz. It incorporates a minimum of
passive support components to configure the amplifier
PERFORMANCE SUMMARY
SYMBOL
PARAMETER
Power Supply
V
Operating Supply Range
CC
I
Current Consumption
CC
POWER GAIN
FREQUENCY
S21
(MHz)
(dB)
100
15.1
200
15.4
240
15.6
300
15.5
400
15.5
500
15.4
600
15.3
700
15.2
800
15.0
900
14.8
1000
14.7
1100
14.5
1200
14.3
Notes: All figures are referenced to J7 (Input Port) and J10 (Output Port).
1. Two-tone test condition: Output power level = +2dBm/tone; Tone spacing = 1MHz.
2. Single-tone test condition: Output power level = +6dBm.
3. Small signal noise figure.
®
6431-15
Specifications are at T
OUTPUT
OUTPUT
THIRD-ORDER
THIRD-ORDER
1
INTERCEPT POINT
INTERMODULATION
OIP3
OIM3
(dBm)
(dBc)
46.6
–89.2
46.7
–89.5
46.7
–89.3
46.6
–89.3
46.1
–88.3
45.3
–86.6
43.5
–83.1
42.2
–80.4
41.1
–78.1
39.5
–74.9
38.7
–73.3
38.0
–71.9
38.0
–71.9
DEMO MANUAL DC1774A-C
50Ω Gain Block IF Amplifier
for various applications. The LTC6431-15 provides 50Ω
single-ended input and output impedance so that it can
be easily evaluated with most RF test equipment.
Design files for this circuit board are available at
http://www.linear.com/demo
L, LT, LTC, LTM, Linear Technology and the Linear logo are registered trademarks of Linear
Technology Corporation. All other trademarks are the property of their respective owners.
= 25°C, V
= 5V
A
CC
CONDITIONS
All V
Pins Plus +OUT
CC
Total Current
SECOND
THIRD
HARMONIC
HARMONIC
1
2
DISTORTION
DISTORTION
HD2
HD3
(dBc)
(dBc)
–58.0
–88.0
–58.0
–88.0
–59.0
–88.0
–60.0
–86.0
–57.0
–87.0
–55.6
–77.0
–53.6
–69.0
–51.9
–69.0
–49.2
–65.0
–46.7
–63.0
–45.0
–59
–40.8
–56.8
–38.4
–54.2
LTC6431-15
VALUE/UNIT
4.75V to 5.25V
90mA
OUTPUT 1dB
COMPRESSION
2
POINT
NOISE FIGURE
P1dB
NF
(dBm)
(dB)
20.0
3.8
20.0
3.5
20.3
3.4
20.1
3.5
20.3
3.5
20.3
3.6
20.4
3.7
20.2
3.8
20.1
4.0
19.7
4.2
19.3
4.2
18.8
4.4
18.6
4.6
dc1774acf
