DEMO MANUAL DC1649A

PARTS LIST

ITEM QTY REFERENCE
1 0 CI1_P , CI1_A, C27, C32, CP_A
2 0 CI2_A
3 1 CI2_P
4 1 CP_P
5 3 C1, C19, C33
6 4 C2, C6, C21, C35
7 2 C3, C16
8 10 C4, C11, C17, C24, C30, C36, C39,
C41, C43, C44
9 4 C5, C12, C18, C31
10 1 C7
11 2 C8, C15
12 3 C23, C34, C45
13 0 C25, C28
14 5 C26, C29, C37, C38, C42
15 1 D1
16 10 E3, E6, E11-E18
17 1 JP1
18 1 XJP1
19 5 J1, J2, J5, J6, J7
20 0 J3, J4
21 1 J8
22 4 J9, J10, J11, J12
23 0 L1
24 2 L2, L3
25 1 RZ_P
26 5 R1, R2, R25, R26, R27
27 1 R4
28 1 R5
29 4 R7, R8, R18, R19
30 4 R9, R10, R14, R16
31 3 R12, R21, R22
32 0 R13, R15, R17, RZ_A
33 0 R23, R24
34 1 U1
35 1 U2
36 1 U3 (1 Reel + 1 Tape, PbF)
37 0 U4
38 2 U5, U6
39 1 U7
40 1 U8
41 4 4 Corners
42 2
6
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
Number of Boards = 325
PART DESCRIPTION
Opt., 0603
Opt., 1206
Cap., C0G, 0.1μF , 50V, 5%, 1206
Cap., X7R, 8200pF , 50V, 10%, 0603
Cap., Tantalum, 47μF , 35V, 10%, 7361
Cap., X7R, 0.1μF , 50V, 10%, 0805
Cap., Tantalum, 330μF , 10V, 10%,7343
Cap., X5R, 0.1μF , 10V, 10%, 0402
Cap., X5R, 1μF , 10V, 10%, 0402
Cap., Tantalum, 47μF , 20V, 10%, 7343
Cap., X7R, 470pF , 50V, 10%, 0402
Cap., X7R, 0.01μF , 16V, 10%, 0402
Opt., 0402
Cap., NPO, 100pF , 16V, 10%, 0402
LED, RED
Turret, Testpoint, 2501
Headers, 3 Pins, 2mm Ctrs.
Shunt, 2mm Ctrs.
Con., SMA 50Ω Edge-Launch
Con., SMA 50Ω Straight Mount
Con., Header, 14 Pin, 2mm
Jack, Banana
Opt., 0402
Ind., Wirebound, 68nH, ±5%, 0402
Res., Chip, 806, 1/10W, 1%, 0603
Res., Chip, 4.99k, 1/16W, 1%, 0402
Res., Chip, 330, 1/16W, 1%, 0402
Res., Chip, 51.1, 1/16W, 1%, 0402
Res., Chip, 200k, 1/16W, 1%, 0402
Res., Chip, 0Ω, 0603
Res., Chip, 100, 1/16W, 1%, 0402
Opt., 0603
Res., Chip, 0402, Opt.
I.C. LTC6945IUFD, QFN28UFD
Low Noise Amp, S0-8
Voltage Controlled Oscillator – VC0
Crystal Oscillator, Opt.
I.C., Dual Buffer, SC-70 6-Lead
I.C., Dual Transceiver, SC-70 6-Lead
I.C., Serial EEPROM, TSSOP-8
Standoff, Nylon, 0.50, 1/2"
Stencils (Top and Bottom)
MANUFACTURER/PART NUMBER
Murata, GRM31C5C1H104JA01L
Murata, GRM188R71H822KA01D
AVX, TAJV476K035RNJ
AVX, 08055C104KAT2A
AVX, TPME337K010R0035
AVX, 0402ZD104KAT2A
AVX, 0402ZD105KAT2A
AVX, TAJD476K020RNJ
AVX, 04025C471KAT2A
AVX, 0402YC103KAT2A
AVX, 0402YA101KAT2A
Panasonic, LN1251CTR
Mill-Max, 2501-2-00-80-00-00-07-0
Samtec, TMM-103-02-L-S
Samtec, 2SN-BK-G
E. F . Johnson, 142-0701-851
Opt.
Molex, 87831-1420
Keystone, 575-4
Coilcraft, 0402HPH-68NXJL
Vishay, CRCW0603806RFKEA
Vishay, CRCW04024K99FKED
Vishay, CRCW0402330RFKED
Vishay, CRCW040251R1FKED
Vishay, CRCW0402200KFKED
Vishay, CRCW06030000Z0EA
Vishay, CRCW0402100RFKED
Linear Technology Corp., LTC6945IUFD
Linear Technology Corp., LT1678CS8#PBF
Crystek, CVCO55CL-0902-0928
Fairchild Semi., NC7WZ17P6X
NXP , 74LVC1T45GW
Mircochip, 24LC24A-I/ST
Keystone, 8833 (Snap On)
Stencil, DC1649A-4
