DEMO MANUAL DC1649A
SCHEMATIC DIAGRAM
Note: The buffers shown on sheet 2 of 2 of the schematic are used to
protect the LTC6945 when communicating to it starts before powering it
up. There is no need for such circuitry if the SPI bus is not active before
