SET-UP AND INSTALLATION
Node-6 Electrical Connections for MAX-ER with Mast Stop Limit Switch
5a
6a (behind)
5b
6b (behind)
View A
Legend for Figure 4-24
Item Component
1 Node 6
2a Receptacle W66
2b W66 Shorting Plug w/ Dust Cap
2c Cable W66
2d Cable W66P8
2e W66P8 Shorting Plug w/ Dust Cap
3a Receptacle W63
3b Cable W63
4a Receptacle W64
4b Cable W64
4c Cable W64P8
5a WN In
5b Cable WN24 or WN26
6a WN Out
6b Cable WN18
4-42
4a 3a 2a
1
2b
Description
Front of Rotating Bed
Drum 1 in Boom Butt
Mast Stop Positioning Sensor
Drum 3 in Boom Butt
Drum 5 in Mast Butt
Mast Stop Positioning Sensor
CAN In
From Wireless Setup Receiver
CAN Out
From Node 3
Published 04-21-17, Control # 227-02_v1
3a 2a
3b
View B
4b
3b
View C
16000 OPERATOR MANUAL
2c
2b
2d
2e
4a 3a 2a
2c
2b
2d
2e
4c
FIGURE 4-24
