PCI-DAS6402/16 User's Guide
40-pin to 37-pin signal mapping
Signal mapping on the C40-37F-x and the BP40-37-x cables is not 1:1. Ta
signals on the 40-pin end and the pin numbers of the associated signals on the 37-pin end.
Table 2-5. Signal mapping on the C40-37F-x and BP40-37F cables
40-pin cable end
Pin Signal Name
1 INTERRUPT IN
2 +5V
3 INTERRUPT ENABLE
4 GND
5 Port B 7
6 Port C 7
7 Port B 6
8 Port C 6
9 Port B 5
10 Port C 5
11 Port B 4
12 Port C 4
13 Port B 3
14 Port C 3
15 Port B 2
16 Port C 2
17 Port B 1
18 Port C 1
19 Port B 0
20 Port C 0
21 GND
22 Port A 7
23 N/C
24 Port A 6
25 GND
26 Port A 5
27 N/C
28 Port A 4
29 GND
30 Port A 3
31 N/C
32 Port A 2
33 GND
34 Port A 1
35 +5V
36 Port A 0
37 GND
38 N/C
39 N/C
40 N/C

Field wiring, signal termination and conditioning

You can use the following MCC screw terminal boards to terminate field signals and route them into the PCI-
DAS6402/16 board using the C100FF-x cable:
! – 16-channel single-ended BNC connector box. Details on this product are available on our web
BNC-16SE
site at www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=101&pf_id=713.
! – Eight-channel differential BNC connector box. Details on this product are available on our
BNC-16DI
web site at www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=101&pf_id=714.
!
– 50-pin screw terminal board. Details on this product are available on our web site at
CIO-MINI50
www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=102&pf_id=258.
! – 100 pin, 16 x 4 screw terminal board. Details on this product are available on our web site
CIO-TERM100
at www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=102&pf_id=281.
! – 50-conductor, shielded signal connection box. Details on this product are available on our web
SCB-50
site at www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=196&pf_id=1168.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
ble 2-5
37-pin cable end
Pin Signal Name
1 INTERRUPT IN
20 +5V
2 INTERRUPT ENABLE
21 GND
3 Port B 7
22 Port C 7
4 Port B 6
23 Port C 6
5 Port B 5
24 Port C 5
6 Port B 4
25 Port C 4
7 Port B 3
26 Port C 3
8 Port B 2
27 Port C 2
9 Port B 1
28 Port C 1
10 Port B 0
29 Port C 0
11 GND
30 Port A 7
12 N/C
31 Port A 6
13 GND
32 Port A 5
14 N/C
33 Port A 4
15 GND
34 Port A 3
16 N/C
35 Port A 2
17 GND
36 Port A 1
18 +5V
37 Port A 0
19 GND
2-9
Installing the PCI-DAS6402/16
lists the pin numbers of the
