You can use the following MCC screw terminal board to terminate field signals and route them into the PCI-
DAS6402/16 board using the C40FF-x cable.
! – 50-pin screw terminal board. Details on this product are available on our web site at
CIO-MINI40
www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=102&pf_id=257.
For digital signal conditioning, you can connect the PCI-DAS6402/16 to the following boards using the C40-
37F-x cable, or the BP40-37 cable with either the C37FF-x or C37FFS-x cable.
! – 37-conductor, shielded signal connection/screw terminal box. Details on this product are
SCB-37
available on our web site at www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=196&pf_id=1166.
! – 37-pin screw terminal board. Details on this product are available on our web site at
CIO-MINI37
www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=102&pf_id=1543.
! – 24 Form C relays, 6 Amp relay accessory board for digital signal conditioning. Details on
CIO-ERB24
this product are available on our web site at
www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=123&pf_id=241.
! – Eight Form C relays, 6 Amp relay accessory board for digital signal conditioning. Details on
CIO-ERB08
this product are available on our web site at
http://www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=123&pf_id=240.
! – 24-position solid state relay rack. Details on this product are available on our web site at
SSR-RACK24
www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=122&pf_id=1193.
! – Eight-channel solid state relay rack. Details on this product are available on our web site at
SSR-RACK08
www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=122&pf_id=620.
