PCI-DAS6402/16 User's Guide
Pin Signal name
1 LLGND
2 CH0 IN
3 CH32 IN
4 CH1 IN
5 CH33 IN
6 CH2 IN
7 CH34 IN
8 CH3 IN
9 CH35 IN
10 CH4 IN
11 CH36 IN
12 CH5 IN
13 CH37 IN
14 CH6 IN
15 CH38 IN
16 CH7 IN
17 CH39 IN
18 LLGND
19 CH8 IN
20 CH40 IN
21 CH9 IN
22 CH41 IN
23 CH10 IN
24 CH42 IN
25 CH11 IN
26 CH43 IN
27 CH12 IN
28 CH44 IN
29 CH13 IN
30 CH45 IN
31 CH14 IN
32 CH46 IN
33 CH15 IN
34 CH47 IN
35 D/A GND 0
36 D/A OUT 0
37 D/A GND 1
38 D/A OUT 1
39 CTR1 CLK
40 CTR1 GATE
41 CTR1 OUT
42 A/D EXTERNAL PACER
43 ANALOG TRIGGER IN
44 DIN0
45 A/D START TRIGGER IN
46 DIN1
47 A/D STOP TRIGGER IN
48 PC +5V
49 SSH OUT / D/A PACER OUT
50 GND
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Table 24. 64-channel single-ended mode pin out
Pin Signal name
51 LLGND
52 CH16 IN
53 CH48 IN
54 CH17 IN
55 CH49 IN
56 CH18 IN
57 CH50 IN
58 CH19 IN
59 CH51 IN
60 CH20 IN
61 CH52 IN
62 CH21 IN
63 CH53 IN
64 CH22 IN
65 CH54 IN
66 CH23 IN
67 CH55 IN
68 LLGND
69 CH24 IN
70 CH56 IN
71 CH25 IN
72 CH57 IN
73 CH26 IN
74 CH58 IN
75 CH27 IN
76 CH59 IN
77 CH28 IN
78 CH60 IN
79 CH29 IN
80 CH61 IN
81 CH30 IN
82 CH62 IN
83 CH31 IN
84 CH63 IN
85 DOUT0
86 DOUT1
87 DOUT2
88 DOUT3
89 GND
90 +12V
91 GND
92 -12V
93 DIN2
94 DIN3
95 A/D INTERNALPACER OUTPUT
96 D/A EXTERNAL PACER INPUT
97 EXTERNAL D/A TRIGGER/PACER GATE
98 A/D PACER GATE
99 EXTERNAL INTERRUPT
100 GND
5-10
Specifications
