PCI-DAS6402/16 User's Guide
The analog output circuits are calibrated for gain and offset. Gain calibration of the analog outputs is performed
via DAC reference front-end calibration system.
Analog output calibration is shown in Figure 4-2. This circuit is duplicated for both DAC0 and DAC1.
Trim DAC
Coarse
Trim DAC
Fine
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
DAC
Ref
Gain
Adjust
Trim DAC
Coarse
Trim DAC
Fine
Figure 4-2. Analog output calibration
4-2
Calibrating the PCI-DAS6402/16
Analog Out
Offset
Adjust
