PCI-DAS6402/16 User's Guide
EXTERNAL D/A TRIGGER/PACER GATE
D/A EXTERNAL PACER INPUT
A/D INTERNAL PACER OUTPUT
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Table 2-3. 64-channel single-ended mode pin out
Signal Name Pin
GND 100
EXTERNAL INTERRUPT 99
A/D PACER GATE 98
97
96
95
DIN3 94
DIN2 93
-12 V 92
GND 91
+12 V 90
GND 89
DOUT3 88
DOUT2 87
DOUT1 86
DOUT0 85
CH63 IN 84
CH31 IN 83
CH62 IN 82
CH30 IN 81
CH61 IN 80
CH29 IN 79
CH60 IN 78
CH28 IN 77
CH59 IN 76
CH27 IN 75
CH58 IN 74
CH26 IN 73
CH57 IN 72
CH25 IN 71
CH56 IN 70
CH24 IN 69
LLGND 68
CH55 IN 67
CH23 IN 66
CH54 IN 65
CH22 IN 64
CH53 IN 63
CH21 IN 62
CH52 IN 61
CH20 IN 60
CH51 IN 59
CH19 IN 58
CH50 IN 57
CH18 IN 56
CH49 IN 55
CH17 IN 54
CH48 IN 53
CH16 IN 52
LLGND 51
↓
PCI slot
2-5
Installing the PCI-DAS6402/16
Pin Signal Name
• • 50 GND
• •
49 SSH OUT/DAC PACER OUT
• •
48 PC +5 V
• • 47 A/D STOP TRIGGER IN
• • 46 DIN1
• • 45 A/D START TRIGGER IN
• •
44 DIN0
• •
43 ANALOG TRIGGER IN
• • 42 A/D EXTERNAL PACER
• • 41 CTR1 OUT
• • 40 CTR1 GATE
• • 39 CTR1 CLK
• •
38 D/A OUT 1
• • 37 D/A GND 1
• • 36 D/A OUT 0
• • 35 D/A GND 0
• • 34 CH47 IN
• •
33 CH15 IN
• • 32 CH46 IN
• • 31 CH14 IN
• • 30 CH45 IN
• • 29 CH13 IN
• • 28 CH44 IN
• • 27 CH12 IN
• • 26 CH43 IN
• • 25 CH11 IN
• • 24 CH42 IN
• • 23 CH10 IN
• •
22 CH41 IN
• • 21 CH9 IN
• • 20 CH40 IN
• • 19 CH8 IN
• • 18 LLGND
• •
17 CH39 IN
• • 16 CH7 IN
• • 15 CH38 IN
• • 14 CH6 IN
• • 13 CH37 IN
• •
12 CH5 IN
• • 11 CH36 IN
• • 10 CH4 IN
• • 9 CH35 IN
• • 8 CH3 IN
• •
7 CH34 IN
• •
6 CH2 IN
• • 5 CH33 IN
• • 4 CH1 IN
• • 3 CH32 IN
• • 2 CH0 IN
• •
1 LLGND
