PCI-DAS6402/16 User's Guide
For signal connections and termination, you can use the CIO-MINI40 screw terminal board and C40FF-x cable.
For connections to 37-pin screw terminal boards, you can use the C40-37F-x cable.
2
40
40-pin Female
IDC Connector
2
40
40-pin Female
IDC Connector
For digital signal conditioning, you can connect the BP40-37 cable to a C37FF-x or C37FFS-x cable, and then
connect one of these cables to the 37-pin connector on MCC's digital signal conditioning boards. Refer to page
2-9 for a list of compatible accessories.
19
1
37-pin Male D Connector
with Backplate Assembly
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
identifies pin # 1
1
39
Figure 2-2. C40FF-x cable
The red stripe
1
identifies pin # 1
39
Figure 2-3. C40-37F-x cable
37
20
The red stripe and arrow
identify pin # 1
Figure 2-4. BP40-37 cable
2-7
Installing the PCI-DAS6402/16
The red stripe
2
40
40-pin Female
IDC Connector
1
19
37-pin Female
Dsub Connector
39
Key
1
40-pin Female
IDC Connector
1
39
20
37
40
2
