Field wiring, signal termination and conditioning

You can use the CIO-STA-TC isothermal block with CJC sensor terminal adapter board to terminate field
signals and route them into the PCI-DAS-TC using the C37FFS-x cable. Details on this product are available on
our web site at www.mccdaq.com.com/products/screw_terminal_bnc.aspx.
Figure 2. C37FFS-x cable
