Sage the Dose Control Pro Instruction Booklet page 12

OPERATING YOUR NEW APPLIANCE
Step 4:
Trimming the Dose
The adjustable Razor™ Dose Trimming Tool
allows you to trim the puck to the right level
for a consistent extraction.
Select the correct width blade of the Razor™
to match the diameter of your filter basket.
The Razor™ has three blades of varying widths:
58mm, 54mm and 50mm. The 58mm and
54mm are already fitted within the Razor™
body. The 50mm is separate.
54mm
If you require the 50mm blade, turn the
Adjustable Dial past #1 until the 54mm blade
is fully extended and able to be pulled from
the body.
NOTE
The Adjustable Dial may feel tight
as you continue to wind it towards
the end of its travel.
Insert the 50mm blade into the body. Wind
the Adjustable Dial until the blade is retracted
past #4. Press the 50mm and 58mm blades
at the same time, towards the centre of the
body until a "click" sound can be heard.
12
50mm
ADDITIONAL BLADE
54mm
50mm
Adjust the Razor™ to the setting in the
table below for your Sage
This is a starting point for your dose height.
Sage Espresso
®
Machine
BES920UK
BES870UK
BES810BSS
After tamping the coffee, insert the Razor™
into the filter basket until it rests on the rim
of the basket. The blade of the dosing tool should
penetrate the surface of the tamped coffee.
If the blade does not penetrate the surface
of the tamped coffee, your coffee is under
dosed. Increase the amount of dosed coffee
by adjusting the GRIND TIME dial.
Rotate the Razor™ back and forth while holding
the portafilter on an angle over the knock box
to trim off a little excess coffee.
APPLY PRESSURE
AT BOTH ENDS
'CLICK'
espresso machine.
®
Portafilter Dose
Size Height
58mm 2
54mm 2.5
54mm 2.5
