PCI-DAS1602/16 User's Guide
Pin Signal Name
1 LLGND
2 CH0 HI
3 CH8 HI
4 CH1 HI
5 CH9 HI
6 CH2 HI
7 CH10 HI
8 CH3 HI
9 CH11 HI
10 CH4 HI
11 CH12 HI
12 CH5 HI
13 CH13 HI
14 CH6 HI
15 CH14 HI
16 CH7 HI
17 CH15 HI
18 LLGND
19 N/C
20 N/C
21 N/C
22 N/C
23 N/C
24 N/C
25 N/C
26 N/C
27 N/C
28 N/C
29 N/C
30 N/C
31 N/C
32 N/C
33 N/C
34 N/C
35 D/A GND 0
36 D/A OUT 0
37 D/A GND 1
38 D/A OUT 1
39 CTR4 CLK
40 CTR4 GATE
41 CTR4 OUT
42 A/D EXTERNAL PACER
43 ANALOG TRIGGER IN
44 D/A EXTERNAL PACER IN
45 A/D EXTERNAL TRIGGER IN
46 N/C
47 N/C
48 PC +5V
49 SSH OUT
50 GND
Table 17. 16-channel single-ended mode
Pin
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
28
Signal Name
FIRSTPORTA Bit 0
FIRSTPORTA Bit 1
FIRSTPORTA Bit 2
FIRSTPORTA Bit 3
FIRSTPORTA Bit 4
FIRSTPORTA Bit 5
FIRSTPORTA Bit 6
FIRSTPORTA Bit 7
FIRSTPORTB Bit 0
FIRSTPORTB Bit 1
FIRSTPORTB Bit 2
FIRSTPORTB Bit 3
FIRSTPORTB Bit 4
FIRSTPORTB Bit 5
FIRSTPORTB Bit 6
FIRSTPORTB Bit 7
FIRSTPORTC Bit 0
FIRSTPORTC Bit 1
FIRSTPORTC Bit 2
FIRSTPORTC Bit 3
FIRSTPORTC Bit 4
FIRSTPORTC Bit 5
FIRSTPORTC Bit 6
FIRSTPORTC Bit 7
N/C
N/C
N/C
N/C
N/C
N/C
N/C
N/C
N/C
N/C
N/C
N/C
N/C
N/C
GND
+12V
GND
-12V
N/C
N/C
A/D INTERNAL PACER OUTPUT
D/A INTERNAL PACER OUTPUT
EXTERNAL D/A PACER GATE
N/C
EXTERNAL INTERRUPT
GND
