3.2 Auto Iris Lens Control Settings (LENS)

Set the mode when using auto iris lens. Move the cursor to LENS with UP/DOWN key and press the ENTER and AUTO IRIS menu will be displayed.
Move the cursor up and down and adjust using LEFT / RIGHT key for the item you want to adjust.

3.2.1 Auto Iris Lens Control Mode (MODE)

Set auto iris lens control mode (MODE). Use LEFT / RIGHT key to select the lens aperture control mode.
*Default : "AUTO"
AUTO
LENS
AUTO
OPEN
CLOSE
* This function will be the following control state by combining with SHUTTER/AGC of "3.3 Shutter/Gain Settings (SHUTTER/AGC)".
Lens in use SHUTTER/AGC
AUTO
Auto Iris
MANUAL
AUTO
Manual
MANUAL
Control the lens aperture automatically.
*AUTO is recommended for standard operation.
Open the lens aperture fully.
Close the lens aperture fully.
(LENS)
MODE
Control the lens aperture automatically.
AUTO
*AUTO is recommended for using auto iris lens.
OPEN Open the lens aperture fully.
CLOSE Close the lens aperture fully.
AUTO The setting is available, but it does not work. The lens aperture opens fully.
OPEN Open the lens aperture fully.
CLOSE Close the lens aperture fully.
AUTO
LENS (MODE) setting is available, but it does not work.
OPEN
CLOSE
ENTER
LEFT/RIGHT
OPEN
OPERATION
OPERATION
