Watec WAT-233 User Manual page 51

○Blemish pixel compensation process flow
(4) Move the cursor on BPC START and press the ENTER key
to execute the blemish pixel compensation again.
(3) When the blemish pixel
compensation is completed
successfully, "FINISH" is
displayed and the screen
returns to the BPC menu screen.
* When saving the correction result after completing the compensation, save the set value according to 『3.18 Save Setting (SAVE ALL)』.
When you do not save the setting value and turn off the power supply, it will return to the setting value before executing the compensation.
*(Note 1): The followings are the factors that cause the message of (4) and (5) to be displayed.
1) The setting value of "DETECT LEVEL" is low and the number of blemish pixel detected during the compensation exceeds the correctable number (64 points).
2)When the lens is not fully closed. (in this case where the lens is open, the bright part on the screen is recognized as blemish pixels,
as a result the number of detections exceeds the correctable number and the message screen of (4) appears as same as in(1)).
When (4) screen is displayed and the compensation is executed again, the camera automatically increases the set value of DETECT LEVEL and operates
the compensation again. Increase amount of DETECT LEVEL increases from 1, 2, 4, 8, 16 from the initial setting value at the time of the compensation execution.
(Ex.) Initial setting value : "0"
First time: 0 → 2nd: 1 (+1) → 3rd: 3 (+ 2) → 4th: 7 (+ 4) → 5th: 15 (+8) → 6th: 31 (+16)
When the comensation is not completed normally even after six repitation, the (5) message is displayed. In that case, make sure that the lens is fully closed
and when the lens is fully closed, increase the set value of DETECT LEVEL and execute the compensation again.
(1) Cover the lens completely and
select BPC START and press the ENTER key.
ENTER
(2) The screen display on the left
continues for about 5 seconds.
(5) When "WAIT" is displayed,
it returns to the screen of (2) and the
compensation works again (*Note 1)
(6) Even if the compensation is repeated six times,
when the correction is not completed normally,
the message on the left is displayed and the screen returns
to the BPC menu screen. (*Note 1)
51
