3.5.1 Auto Trace White Balance (ATW)

ATW maintains color reproducibility even when the color temperature of the light source changes.
Light source color temperature = 3000K
When ATW is selected, pressing the ENTER key will display the ATW SETUP. Move the cursor up or down with the UP / DOWN key and
Use the LEFT / RIGHT keys to adjust the ATW.
WB
(ATW SETUP MENU)
SPEED
ATW
DELAY CTL

3.5.2 Auto White Balance (AWB)

AWB controls white balance a wider color temperature range than ATW regardless of subject condition and maintains color reproducibility.
*The mode can not set the control speed and the pull-in frame.
LEFT/RIGHT
Light source color temperature = 4300K
Set the pull-in speed. The lead-in speed can be set in the range 000 - 255.
The lower the set value, the faster the pull-in speed, and the larger the set value, the slower the pull-in speed.
*Note : color oscillation is likely to occur if the pull-in speed is set too fast.
*Default : 005
Set the time from the change in color temperature to the start of white balance control.
Selectable in the range 000 - 255. The lower the set value, the faster to start WB control, the higher the set
value, the slower to start WB control.
*Default : 005
ENTER
OPERATION
25
Light source color temperature = 6000K
