3. MAIN MENU/SETUP MENU

When pressing ENTER key, SETUP menu will appear on the screen.

OSD Menu is consist of 3 pages (SETUP MENU1/3, SETUP MENU2/3 and SETUP MENU3/3).

SETUP MENU 1/3

When you change the camera setting through the OSD, you can save the changed

setting by executing "SAVE ALL". Please make sure to save the setting before

turning off the power when you set the opyimum function in customer's

environment. When you turn off the power without saving, please be careful as it

will return to the state before the setting change.

Please refer to "3.18 Save Settings (SAVE ALL)" when saving the settings.

OSD = OFF

ENTER

SETUP MENU 2/3

OSD = ON

SETUP MENU 3/3
