Technical Characteristics - Controlli MVE2R Series Datasheet

Manual operation handle can also be used to modify any DIP switch
setting or as re-set function after any alarm occurrence.
The actuator is supplied with the manual override lowered (ON). It
is not necessary to remove power supply to modify DIP switches set-
ting, but, in this case, pay attention to 230V high voltage presence.
Position Feedback
The actuator utilizes a 2-10V position feedback (look at DIP n. 1 set-
tings).
Calibration
The actuator has both auto and manual stroke calibration. The ac-
tuator is delivered with DIP n. 7 set to auto. Manual calibration is not
necessary unless maintenance is required on the valve or certain
alarm functions are desired.
End Point Auxiliary Switches (with accessory DMVE)
End point switches change over when the valve is fully open or
closed. They are free contacts with 24V AC/DC, 4A max voltage on
terminals. End point switches can be utilized to indicate valve stroke
end positions and for relay control of additional plant equipment.
When the actuators are controlled individually or in sequence, it is
possible to use the end switches to toggle when the valve is fully
open or fully closed. The auxiliary switch position according to con-
trol signal (Y) is shown in the picture below.
Control signal (Y)
0-0,5Vdc
0,5-9,5Vdc
9,5-10Vdc
CLOSING RELAY
K1 K2 KC1
Diagnostic
The actuator is provided with a self diagnostic algorithm able to de-
tect faulty conditions:
• stroke calibration out of range 5-60mm;
• unexpected stall condition (e.g. valve stuck or extra stroke due
to actuator link loose);
• voltage supply out of range.
These faulty conditions are signalled via the GREEN and RED LED on
the lower electronic board blinking accordingly (see "Diagnostic –
Alarm Function Table").
Relay Relay
KC1 KC2
KC1 to K2 KC2 to K3
KC1 to K1 KC2 to K3
KC1 to K1 KC2 to K4
DMVE
OPENING RELAY
K3 K4 KC2
1 Issue rev. b
st

TECHNICAL CHARACTERISTICS

Power supply F N
Power consumption
(running)
Power consumption
(holding)
Charging phase
consumption
Ultracapacitors charging
phase
(if totally discharged)
Running and emergency
return time
Modulating with Controlli
valves stroke 16,5mm
Modulating with Controlli
valves stroke 25mm
Modulating with Controlli
valves stroke 45mm
Floating
Transformer Size [VA]
Stroke
Force
Duty cycle
voltage 0-10V - impedance > 100kΩ (range:
Analogue input Y M 0-10Vdc, 2-10Vdc, 0-5/2-6Vdc, 5-10/6-10Vdc)
Digital inputs Y1 Y2
Output V+
Output U
Number of cycles of
emergency
Type of movement
Ambient temperature
Ambient Humidity
Protection degree IP54 (with PG13,5 cable gland - not supplied)
Insulation class
Emission/Immunity EMC 2004/108/CE according
Standard
Material
Colour
Weight [kg]
Dimensions [mm]
04/2016 DBL462e
MVE206R MVE210R
MVE206SR MVE210SR
230Vac ±10%, 50-60Hz
13VA/6W 18VA/8W
11VA/5W 11VA/5W
32VA/18W
130s
1,1s/mm
18s
28s
50s
60s
50 60
5-60mm (limited to 30mm for MVE.SR)
600N 1000N
max 50%/60 minutes
500Ω (range 4-20mA)
connection of Y1, Y2 to M
voltage 16Vdc ± 0,5V
max load 25mA,
voltage 2-10Vdc (0-100%)
max load 2mA
1.000
linear
operation -10T50°C; storage -20T50°C
max 90% RH
to EN 61326-1;
LVD 2006/95/CE according to EN61010-1.
housing: aluminium - cover: ABS plastic
aluminium / white
1,7 (MVE2xxR); 1,6 (MVE2xxSR)
refer to the picture on the page 7
MVE215R
MVE215SR
21VA/11W
13VA/7W
80
1500N
Page 2
