Technical Characteristics - Controlli MVE2 Series Quick Start Manual

End Point Auxiliary Switches (with accessory DMVE)
End point switches change over when the valve is fully open or
closed. They are free contact with 24V AC/DC, 4A max voltage to
terminals.
End point switches can be utilized to indicate valve stroke end posi-
tions and for relay control of additional plant equipment. When the
actuators are controlled individually or in sequence, it is possible to
use the end switches to toggle when the valve is fully open or fully
closed. The auxiliary switch position according to control signal (Y) is
shown in the table below.
Control signal
(Y)
0-0,5Vdc
0,5-9,5Vdc
9,5-10Vdc
CLOSING RELAY
K1 K2 KC1
Diagnostic
The actuator is provided with a self diagnostic algorithm able to de-
tect faulty conditions:
• stroke calibration out of range 5-60mm;
• unexpected stall condition (e.g. valve stuck or extra stroke due
to actuator link loose);
• voltage supply out of range.
These faulty conditions are signalled via the GREEN and RED LED on
the electronic board blinking accordingly (see Diagnostic – Alarm
Function Table).
Relay Relay
KC1 KC2
KC1 to K2 KC2 to K3
KC1 to K1 KC2 to K3
KC1 to K1 KC2 to K4
DMVE
OPENING RELAY
K3 K4 KC2
1 Issue rev. d
st

TECHNICAL CHARACTERISTICS

MVE206
MVE206S
Supply voltage F N
Power consumption
13VA / 6W
(running)
Power consumption
11VA / 5W
(holding)
Running time
Modulating 5-15mm
Modulating 15-25mm
Modulating 25-60mm
Increase/decrease
Stroke [mm]
Force [N] 600
Duty cycle
voltage 0-10V - impedance > 100kΩ (range:
Analogue input Y M 0-10Vdc, 2-10Vdc, 0-5/2-6Vdc, 5-10/6-10Vdc)
Digital inputs Y1 Y2
Output V+
Output U
Room temperature
Room humidity
Protection degree IP54 (with PG13,5 cable gland - not supplied)
Insulation class
Emission/Immunity EMC 2004/108/CE according to
Standard
LVD 2006/95/CE according to EN61010-1 standard
Material
Colour
Weight [kg]
Dimensions [mm]
01/2016 DBL394e
MVE210 MVE215
MVE210S MVE215S
230Vac ±10%, 50-60Hz
18VA / 8W 21VA / 11W 25VA/10W
11VA / 5W 13VA/7W
15s
20s
30s
60s
5-60mm (limited to 30mm for MVE.S)
1000 1500
max 50%/60 minutes
500 Ω (range 4-20mA)
connection of Y1, Y2 to M
voltage 16Vdc ± 0,5V
max load 25mA,
voltage 2-10Vdc (0-100%)
max load 2mA
operation and storage -10T50°C
max 90% R.H.
EN 61326-1:2006 standard
housing: aluminium - cover: ABS plastic
aluminium / white
1.7 (MVE2xx); 1.6 (MVE2xxS)
refer to the picture on the page 7
MVE222
MVE222S
10VA/4W
60s
2200
Page 2
