Control signal (Y)
0-0,5Vdc
0,5-9,5Vdc
9,5-10Vdc
CLOSING RELAY
K1 K2 KC1
Diagnostic
The actuator is provided with a self diagnostic algorithm able to
detect faulty conditions:
• stroke out of range 5-60 mm;
• unexpected stall condition (e.g., valve stuck);
• missing expected stall condition(e.g., link loose);
• voltage supply out of range.
These faulty conditions are signalled via the GREEN and RED LED on
the electronic board blinking accordingly (see "Diagnostic – Alarm
Function Table").
Relay Relay
KC1 KC2
KC1 to K2 KC2 to K3
KC1 to K1 KC2 to K3
KC1 to K1 KC2 to K4
DMVE
OPENING RELAY
K3 K4 KC2
1 Issue
st

TECHNICAL CHARACTERISTICS

Supply voltage L1 Ln
Power consumption
Modulating 5-15mm
Modulating 15-25mm
Modulating 25-40mm
Modulating 40-60mm
Floating
Transformer Size [VA]
Stroke
Force [N]
Duty cycle
Analogue input Y M
Digital inputs Y1-Y2
Output V+
Output U
Cable glandes
Type of movement
Ambient temperature
Ambient Humidity
Protection degree
Insulation class
Standard
Weight [kg]
Dimensions [mm]
05/2017 DBL466e
MVH56E MVHE3K
AC: 24Vac ±20% 50-60Hz
DC:22-30Vdc (Reference Ln)
12VA/5.2W 17VA/8.5W
15s
25s
35s
50s
60s
50 60
5-60mm
1500 3000
max 50%/60 minutes
Voltage 0-10V - impedance > 100kΩ
(range: 0-10 2-10 0-5/2-6 5-10/6-10)
500Ω (range 4-20mA)
Connection to L1 or Ln when
powered in AC
Connection to Ln only when
powered in DC
Voltage 16Vdc ± 0,5V
Max Load 25mA,
Voltage 2-10Vdc (0-100%)
Max Load 2mA
plastic punchable, replaceable by
PG13,5 compression glands
linear
Operation and storage -10/+50°C
max 90% RH
IP55 DIN40050 (IEC 529) for highly
polluted environments according
to IEC 730-1 (93)/6,5,3
Emission/Immunity EMC 2004/108/
CE according to EN 61326-1:2006
standard
4
Refer to the picture on page x
