TERMINAL BLOCK
F N
230~V ±10%
* Floting only sink (connect Y1, Y2 to M)
(*) In order to use the floating control the only possible connection is
between terminal M and Y1/Y2. Do not connect Y1/Y2 to phase
(F) or neutral (N).
Label Description
F
230Vac
N
Y 0..10Vdc
Modulating
M 0V (Common)
Y1 Open
Y2 Close
V+ 16 Vdc
M 0V (Common)
(max 25mA)
U 2÷10Vdc
M 0V (Common)
Note: To avoid damages to electronic components caused by the
PCB bending, do not press too much while fixing the terminal
block.
GROUND CONNECTIONS
Connect the ground terminal to the proper screw labelled with the
ground symbol as shown in the picture here below.
U Y M Y1 Y2
*
Function Wire Size
AWG16
(min 1mm -
2
max 1.5mm )
2
Power
Supply
AWG20
(min 0.5mm -
2
max 1.5mm )
2
Control
Input
AWG20
(min 0.5mm -
2
Floating
max 1.5mm )
2
Control
Input
AWG20
(min 0.5mm -
2
Voltage
max 1.5mm )
2
Output
AWG20
(min 0.5mm -
2
Feedback
max 1.5mm )
2
Output
Signal
ground terminal
1 Issue rev. b
st
SAFETY PRESCRIPTIONS
230 V products
•
Install on the power supply line a protecting device to avoid
short circuits (fuse or magneto-thermic) according to the spec-
ifications in force;
• in case of accidental removal of the cover to make sure that
power is disconnected before working on the actuator or near it;
• the products are maintenance free.
WIRING DIAGRAMS
Max wire
Length
230Vac
Controller
75m
200m
200m
Neutral
200m
Modulating Control (0-10Vcc)
230Vac
Controller
200m
Command +
Command -
Neutral
04/2016
3-point Floating Control
MVE
Open Y1 F
Close
Y2
M
MVE
Y
M
DBL462e
N
F
N
