DIP SWITCHES AND JUMPER SETTINGS

Set the DIP switches according to the tables here below. In order to be sure that any modification has been accepted by the actuator,
power down and power it up again or act on the manual operation handle.
Factory settings
Jumper for emergency re-
turn position selection (open
jumper - totally retracted
joint; closed jumper - totally
extended joint)
Ultracapacitors
Dip
switch
U= feedback
1
Modulating Control (MOD) (Input between Y [+] and M [-])
2
3
4
Sequence Control 0-5Vdc with DIP n. 4 OFF only
5 Sequence Control 2-6Vdc with DIP n. 4 ON only
6
Automatic Calibration: the actuator updates the stroke range if
7
an unexpected mechanical stop is detected for at least 10s
RED LED (ultraca-
pacitors status)
GREEN LED (ultra-
capacitors status)
OFF
Direct Action
-
Modulating Control 0-10Vdc
(DIP n. 2 OFF only)
(DIP n. 3 ON only)
Voltage Input Signal Vdc
(input between Y [+] and M [-])
1 Issue rev. b
st
open jumper
-
retracted joint
U= feedback
U = 2V
U = 10V
3 point floating (INC) ( Y1 open-extend , Y2 close-retract
Selection of sequence mode, control range defined by DIP
Sequence Control 5-10Vdc with DIP n. 4 OFF only
Sequence Control 6-10Vdc with DIP n. 4 ON only
(input between Y [+] and M [-]). In this case DIP n. 4 must be
Manual Calibration: the actuator calibration is started
moving the DIP from OFF to ON or vice versa. With DIP in
ON in case of extra stroke or if an unexpected endpoint is
detected, the actuator will never update the stroke
04/2016
closed jumper
extended joint
ON
Reverse Action
connected to M)
Y1
Y2
n. 5
Modulating Control 2-10Vdc
(DIP n. 2 OFF only)
(DIP n. 3 ON only)
Current Input Signal 4-20mA
set to ON.
