- Page 1 10.1” S-Series HMI W10FA3S-PCH2AC-PoE W10FA3S-PCH2-PoE Quick Start Guide V1.0 Document Part Number: 9152100I0001 Please read these instructions carefully before using this product, and save this manual for future use.
-
Page 2: Table Of Contents
Setting up the Device Home Screen Quick Settings Ethernet AP Configuring Ethernet Checking Ethernet Testing LED Light Bar Reading NFC Tag Using Front Camera The Camera Menu Shooting Photos Shooting Videos Winmate® Home Manager (WHM) How to Lock Applications How to Unlock Applications... - Page 3 How to Change Password Software Developer Support Winmate Software Development Kit Technical Specifications HMI Device Specifications NFC Tag Support...
-
Page 4: Getting Started
Congratulations on purchasing Winmate® 10.1” S-Series HMI. Interactive and smart automation systems of intelligent buildings are in a fast growing phase. Winmate multi-touch S-Series HMI is suitable for home automation and room management systems. Flat surface is easy-to-clean and delivers aesthetically pleasing look for any interior. -
Page 5: Unpacking
Unpacking Carefully remove the box and unpack your device. Please check if all the items listed below are inside your package. If any of these items are missing or damaged contact us immediately. Standard factory shipment list: Quick Start Guide Driver CD &... -
Page 6: Description Of Parts
Description Of Parts W10FA3S-PCH2AC-PoE W10FA3S-PCH2AC-PoE... -
Page 7: Dimensions
Dimensions Dimensions (W x L x H): 263.28 x 171 x 35.7 mm *Note: Measurements shown in mm. **Note: this is a simplified drawing and some components are not marked in detail. Please read these instructions carefully before using this product, and save this guide for future use. -
Page 8: Mounting
Mounting S-series HMI devices come with different mounting options suitable for most of the industrial and commercial applications. VESA Mount Dimensions Screw hole diameter Compatibility 75 x 75 mm VESA M4x3 mm Swing arm mounting kits Flush/ Panel Mount Wall cutout Screw hole diameter 157.6 x 249 mm M3x4 mm... -
Page 9: Connector Description
Connector Description This section explains how to connect external interfaces to the HMI device. DC Input Terminal Block Connector DC power source input is a 3 pin terminal block connector. Minimum Voltage 11.4V Maximum Voltage 12.6V Maximum Current 4.2A Voltage Serial Port Connector Use COM1 serial port connector to connect your HMI to external devices such as mouse, modem or printer. -
Page 10: Usb 2.0 Connector
USB 2.0 Connector Use USB A Type (USB 2.0) connector to connect your HMI device to other USB 2.0 compatible devices. USB1 / USB2 Pin № Pin № Name Name USB_D- USB_D+ USB_D- USB_D+ USB OTG Connector Use USB OTG connector to connect the HMI device to other USB On-The-Go compliant devices such as flash drives, digital cameras, mice or keyboards. -
Page 11: Turning On Or Off
Turning On or Off Turning ON Follow the following steps to turn on your device: 1. Connect HMI device to a thermal block (3-pin). 2. Connect the other side of the thermal block to the AC adapter. 3. Connect the AC adapter to the power cord. 4. -
Page 12: Turning Off
Turning OFF To TURN OFF the HMI device disconnect the power cord from the source of power and the device will automatically shut down. -
Page 13: Configuring Serial Port Settings
Configuring Serial Port Settings Serial COM Port can be configured for RS-232, RS-422 or RS-485. Winmate provide COM port settings application for Android OS. Step 1 Settings > Accessibility Step 2 Accessibility > Comport-Setting Please read these instructions carefully before using this product, and save this guide for future... - Page 14 Step 3 GO to Comport-Setting > Comport 1/ Comport 2/ Comport 3 * Select Comport 1/ Comport 2/ Comport 3 that you want to configure. Step 4 In COM port settings select Comport 1 > RS232/RS422/RS485 *This example shows how to configure Comport 1 settings...
-
Page 15: Brightness Adjustment
Brightness Adjustment Use can adjust the screen brightness in Android settings. Pull down from the top of the screen to get the notifications area. You can also access display settings in the settings menu. Go to Settings > Display > Brightness Tap the cursor to the left to reduce the screen brightness. -
Page 16: Operating The Hmi Device
Operating the HMI Device Winmate® 10.1” S-Series HMI runs on Android 4.4 operating system. Setting up the Device When you first turn on your HMI device, you will see a Welcome screen. Choose the language you want and touch Start or the Start icon. When prompted, you can sign in with your Google Account to create one at that time. -
Page 17: Quick Settings
Quick Settings To open Settings, Swipe down from the top right of the screen and touch the Settings icon. You can open your device’s Settings app from the All Apps screen or from Quick Settings. For example, to change notification sounds, and volume go to Settings >... -
Page 18: Configuring Ethernet
Step 3 Ethernet APP main menu appears Setting Description Check Ethernet Check Ethernet connection parameters: IP mode, IP address, DNS address and others Configure Enable Ethernet connection and configure its such as Ethernet connection type Advanced Configure advanced parameters of the Ethernet Settings Configuring Ethernet To configure Ethernet settings go to Apps >... -
Page 19: Checking Ethernet
Connection Type Setting Description DHCP The device automatically capture IP-address from the router Static IP Allows to manually set up IP-address, DNS, Network and Gateway Checking Ethernet To check the Ethernet settings go to APPS > Ethernet > Check Ethernet Ethernet settings menu appears on the top right side of the desktop. -
Page 20: Reading Nfc Tag
Adjust the intensity of Red, Green and Blue light. Reading NFC Tag Notice that NFC Reader is an optional feature for 10.1” S-Series HMI and may not be present in your device. Refer to Appendix A of this user manual for more details of supported NFC card type. - Page 21 Step 2 User needs to turn the NFC on. If the NFC is off, click on the screen to change NFC & wireless settings. Step 3 The NFC Tag Info application opens Wireless & network settings. In NFC menu slide the bar to the right to turn on the NFC.
- Page 22 Step 4 Go back to NFC Tag Info application. Now you can scan NFC tag. Locate the card to the NFC tag. Don’t remove tag, reading may take up to a minute. Step 5 The information written on the card displays on the screen.
-
Page 23: Using Front Camera
Using Front Camera Notice that 2MP Front Camera is an optional feature for 10.1” S-Series HMI and may not be present in your device. The Camera Menu To open the camera, open All APPS , and then tap on camera icon Item Icon Description Action... -
Page 24: Shooting Photos
Shooting Photos 1 Open the Camera 2 Focus on the object 3 Tap to capture the object 4 By default, the photo preview is displayed briefly on the screen The preview screen automatically closes after 3 seconds. Alternatively, do one of the following: Icon Description... - Page 25 Item Icon Description Action Location Tap to change location settings. Countdown Tap to set countdown timer. timer Picture size Tap to change picture size. Camera Settings to open camera settings. Item Icon Description Action Tap to zoom in or zoom out the Zoom in/ Zoom out picture.
-
Page 26: Shooting Videos
Shooting Videos Short tap > Tap to make a video. Shooting Panoramic Images Short tap > Tap to make panoramic pictures. -
Page 27: Winmate® Home Manager (Whm)
Winmate® Home Manager (WHM) Winmate® S-Series HMI running on Android OS comes with preinstalled APP named Winmate® Home Manager (WHM) which let the device manager to lock the launcher then the user can only use one application assigned by the device manager. - Page 28 Set the WHM password (Default password is “0000”). About Displays information about Winmate® Home Manager Step 2 Go to “Application Selector”, and choose the app which you want to run up automatically after booting. Step 3 Go back to “Home Selector” and press “Clear and Reset Default...
- Page 29 Step 4 Select “Restrict Home” and “Always”, and then restart the computer to enable these settings. The system will automatically start the application which you selected and lock it. Any time user press home key or back key, the system will go back to the same application which you have selected.
-
Page 30: How To Unlock Applications
How to Unlock Applications Follow the instruction below to reset WHM. Step 1 If you want to reset the home manager, pull down the left side to open the status bar and open HomeManager service. Step 2 System will request the password to login. Default password is “0000”. -
Page 31: How To Change Password
Step 3 Restart the system and you will go back to the normal Launcher. How to Change Password Step 1 Go to Password Manager and set your own password for this APP. Step 2 The default password is “0000”. Enter a new password in New Password field, and then tap Change Password. -
Page 32: Software Developer Support
Android USB OTG Driver To find the Drivers and SDK, please refer to the Driver CD that comes in the package or contact us. Also, you can download drivers from Winmate Download Center or Winmate File Share. Winmate Download Center Go to http://www.winmate.com.tw/... -
Page 33: Technical Specifications
Technical Specifications HMI Device Specifications Model Name W10FA3S-PCH2AC-PoE/ W10FA3S-PCH2-PoE Size 10.1" TFT (widescreen) Resolution 1280 x 800 Brightness ( 300 cd/m (typ.) Display Contrast Ratio 800:1 (typ.) Specifications Viewing Angle -89~89 (H); -89~89 (V) Max Colors 262K (6bit) Touch Projective-capacitive touch Freescale®... - Page 34 Serial Port 2 x RS-232 (Default RS-422/optional 485) 2 x USB 2.0 host USB Port 1 x USB OTG I/O Connectors Ethernet Port 1 x RJ 45-10/100/1000 Mbps (LAN/ PoE) Memory 1 x Micro SD card Peer-to-peer, Full ISO 18092(up to 424 Kbits/s) Reader/writer, ISO 14443-A-B, MIFARE, FeliCa NFC Forum tags, ISO 15693 Peripheral...
-
Page 36: Nfc Tag Support
NFC Tag Support The NFC Reader of this device supports the following card type. Supported Card Type (13.56MHz) NFC Forum Platform Type 1, Type 2, Type 3, Type 4 ISO 15693 TI HF-I Plus, TI HF-I Pro, NXPI-Code SLI ISO 14443-A NXP Mifare_One(S50_4byte), NXP Mifare_One(S50_7byte), NXP Mifare_One(S70_4byte),... - Page 37 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, Taipei 241, Taiwan, R.O.C Tel: 886-2-8511-0288 Fax: 886-2-8511-0211 Email: sales@winmate.com.tw Official website: www.winmate.com...
