- Page 1 7” S-Series HMI W07IB3S-PCM1AC-POE W07IB3S-PCM1-POE Quick Start Guide V1.2 For more information on this and other Winmate products, please visit our website at: www.winmate.com Please read these instructions carefully before using this product, and save this manual for future use.
- Page 2 Document Part Number: 9152070I1002...
- Page 3 FCC Statement This device complies with part 15 FCC rules. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a class "B"...
- Page 4 European Union Electromagnetic Compatibility Directive (2014/30/EU) EN55024: 2010/ A1: 2015 o IEC61000-4-2: 2009 o IEC61000-4-3: 2006+A1: 2007+A2: 2010 o IEC61000-4-4: 2012 o IEC61000-4-5: 2014 o IEC61000-4-6: 2014 o IEC61000-4-8: 2010 o IEC61000-4-11: 2004 EN55032: 2012/AC:2013 EN61000-3-2:2014 EN61000-3-3:2013 Low Voltage Directive (2014/35/EU) ...
- Page 5 Brand and product names are trademarks or registered trademarks of their respective owners. Disclaimer Winmate Inc. reserve the right to make changes, without notice, to any product, including circuits and/or software described or contained in this manual in order to improve design and/or performance. We...
- Page 6 Customer Service We provide a service guide for any problem by the following steps: First, visit the website of our distributor to find the update information about the product. Second, contact with your distributor, sales representative, or our customer service center for technical support if you need additional assistance.
- Page 7 Safety Information WARNING! / AVERTISSEMENT! Always completely disconnect the power cord from your chassis whenever you work with the hardware. Do not make connections while the power is on. Sensitive electronic components can be damaged by sudden power surges. Only experienced electronics personnel should open the PC chassis.
-
Page 8: Table Of Contents
- 23 - Connecting to Other Devices - 24 - Mounting - 26 - SPECIFICATIONS - 32 - APPENDIX - 34 - Appendix A: Cleaning the Monitor - 34 - Appendix B: Winmate Software Development Kit - 35 - - 8 -... -
Page 9: Introduction
7” HMI. Interactive and smart automation systems of intelligent buildings are in a fast growing phase. Winmate® multi-touch S-Series HMI is suitable for home automation and room management systems. Flat surface is easy-to-clean and delivers aesthetically pleasing look for any interior. By connecting to centralized database, it can provide real time update for booking status and available schedule, or perform as a synchronous display in meetings. -
Page 10: Package Contents
Package Contents Carefully remove the box and unpack your device. Please check if all the items listed below are inside your package. If any of these items are missing or damaged contact us immediately. Standard factory shipment list: Quick Start Guide Driver CD &... - Page 11 Package may include optional accessories based on your order: VESA Wall Mount VESA Desk Stand VESA Desk Stand Bracket PCVS-V1 LA-100 LA-106 99KK00A0000E 9B0000000128 9B0000000412 Glass Wall Mount Kit Right: PCGM-V1L Left: PCGM-V1L Right: 99KN00A00013 Left:99KN00A00012 - 11 -...
-
Page 12: Product Overview
Product Overview No. Description No. Description ① ⑥ RJ-45 (LAN) 1 Watt Speaker ② ⑦ USB 3.0, USB 2.0 2MP Front Camera (Optional) RGB LED Light Bar ③ ⑧ RS-232 (W07IB3S-PCM1AC only) 12V DC Terminal ④ ⑨ HF RFID Reader (Optional) Block ⑤... -
Page 13: Getting Started
GETTING STARTED Turning On Your Device Follow the following steps to turn on your device: 1. Connect the AC adapter to the DC-in jack connector on the back side of the HMI device. 2. Connect the power cord to AC adapter. 3. -
Page 14: Operating The Hmi Device
Operating the HMI Device Winmate® 7” S-Series HMI comes with HoT Tab, which allows you to operate the HMI device. Hot Tab Menu To open the Hot Tab menu: 1. Double-click the Hot Tab icon on the Windows desktop. 2. The Hot Tab main menu will appear on the screen as shown below. - Page 15 Brightness Tap Brightness button to show current brightness level. To reduce the brightness, drag by touch this icon to the left. To enhance the brightness, drag by touch this icon to the right. Tap Close icon to save the changes and exit the interface. Volume Tap Volume button to show current brightness level.
- Page 16 Testing LED Light Bar Tap Light Bar to access the LED light bar control panel, and select Red / Green / Blue/ Orange color to be displayed on the LED Bar. Performance User can adjust the performance level of the HMI device. There are four options available: ...
-
Page 17: Using Front Camera
Using Front Camera Your device might have built-in camera based on your order. Camera Interface Perform one of the following to open the camera: 1. Press the F1 key. 2. Tap then double-tap to display the HotTab screen. Select Camera. Item Description Tap to record videos... - Page 18 Shooting Photos To make a photo: 1. Open the Camera. 2. Focus on the object. 3. Tap to capture the object. 4. By default, the photo preview is displayed briefly on the screen. The preview screen automatically closes after 3 seconds. Alternatively, do one of the following: - Tap to delete the photo and return to the camera screen.
- Page 19 Recording Videos To record a video: 1. Open the Camera. 2. Focus on the object. 3. Tap to record the video. The video recording screen appears 4. Tap to stop recording and return to the camera screen. 5. To playback the video, browse for the video file and play using a media player application on your device.
- Page 20 Camera Settings 1. Tap to open the setting page 2. Modify necessary settings. - 20 -...
- Page 21 Item Description Check one of the check boxes to show the preview screen right after capturing a photo. • Show Preview: Check this box and enter the preview duration on Close preview after. When the duration ends, Preview Setting the preview screen will automatically close.
-
Page 22: Turning Off Your Device
Turning Off Your Device You can Turn OFF the HMI device with the Windows power settings. To shut down the device: 1. Tap Start >Shut down. 2. Wait for your HMI device to completely turn off before disconnecting the power cord (if necessary). - 22 -... -
Page 23: Installation
INSTALLATION Wiring Requirements The following common safety precautions should be observed before installing any electronic device: Strive to use separate, non-intersecting paths to route power and networking wires. If power wiring and device wiring paths must cross make sure the wires are perpendicular at the intersection point. -
Page 24: Connecting To Other Devices
Connecting to Other Devices Power Input Connector DC power source input is a 3 pin terminal block connector that supports 12V DC power input. Minimum Voltage 11.4V Maximum Voltage 12.6V Maximum Current 4.2A Voltage Serial Port Connector Use COM1 serial port connector to connect your HMI to external devices such as mouse, modem or printer. - Page 25 IMPORTANT: Power Device (PD): follows IEEE 802.3at (25 Watt) USB A Type Connector Use USB A Type (USB 2.0) connector to connect your HMI device to other USB2.0 compatible devices. Use USB 3.0 connector to connect your HMI device to other USB 3.0 compatible devices.
-
Page 26: Mounting
Mounting S-series HMI devices come with different mounting options suitable for most of the industrial and commercial applications. Panel Mounting Panel / Flush Mounting solution allows installing the HMI device onto the wall. Wall Cutout Screw Hole Diameter 131.4 x 175.4 mm M3x4 mm Mounting Instruction 1. - Page 27 VESA Mounting VESA Desk Stand PCVS-V1 The HMI device can be installed on a desk with the stand. You can purchase desk stand as an optional accessory. Model Name: PCVS-V1 Part Number: 99KK00A0000E Mounting Instruction Use provided Philips M4x5 screws to fix the desk stand to VESA holes on the back cover of the device.
- Page 28 VESA Desk Stand LA-100 The HMI device can be installed on a desk with the stand. You can purchase desk stand as an optional accessory. Model Name: LA-100 Part Number: 9B0000000128 Mounting Instruction Use provided Philips M4x5 screws to fix the desk stand to VESA holes on the back cover of the device.
- Page 29 VESA Wall Mount Bracket LA-106 The HMI device can be installed on a desk with the stand. You can purchase desk stand as an optional accessory. Model Name: LA-106 Part Number: 9B0000000412 Mounting Instruction - 29 -...
- Page 30 Accessories Dimensions - 30 -...
- Page 31 Glass Wall Mounting The HMI device can be installed in a glass wall either from right side or from the left. You can purchase Winmate Glass Wall Mount Kit as an optional accessory. Right Side Left Side Model Name: PCGM-...
-
Page 32: Specifications
SPECIFICATIONS HMI Device Specifications Model Name W07IB3S-PCM1AC-POE W07IB3S-PCM1-POE 7” TFT (Widescreen) Size Resolution 1024 x 600 Brightness 500 (typ.) Display Contrast Ratio 700 : 1 (typ.) Specification Viewing Angle -75~75 (H);-70~75(V) Max Colors 16.7M Projected Capacitive Multi- Touch Touch (P-CAP) Intel ®... - Page 33 1 x RJ 45-10/100/1000 Mbps Ethernet Port (LAN), 1 x RJ-45 (PoE) Camera 2 MP Front Camera Audio Output 1 x 1 Watt Speaker Peripheral LED Light Bar Built-in RGB LED light bar Indicator (only for W07IB3S-PCM1AC) Power Input 12V DC Power Power Management...
-
Page 34: Appendix
APPENDIX Appendix A: Cleaning the Monitor Before cleaning: Make sure the device is turned off. Disconnect the power cable from any AC outlet. When cleaning: Never spray or pour any liquid directly on the screen or case. ... -
Page 35: Appendix B: Winmate Software Development Kit
Appendix B: Winmate Software Development Kit Winmate® provides Software Development Kit (SDK). The table below lists SDK provided by Winmate: Item File Type Description Watchdog SDK Watchdog Utility Utility To find the Drivers and SDK, please refer to the Driver CD that comes in the package or contact us. - Page 36 NOTES _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ - 36 -...
- Page 37 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C Tel: 886-2-8511-0288 Fax: 886-2-8511-0211 Email: sales@winmate.com.tw Official website: www.winmate.com...
