7" S-Series HMI
W07IB3S-PCM1AC
W07IB3S-PCM1
Quick Start Guide
V1.2
For more information on this and other Winmate
products, please visit our website at:
www.winmate.com
Document Part Number: 9152070I1002
Please read these instructions carefully before using this product, and save this manual for future use.
Advertisement
Table of Contents
Related Manuals for Winmate 7” S-Series
Summary of Contents for Winmate 7” S-Series
- Page 1 W07IB3S-PCM1AC W07IB3S-PCM1 Quick Start Guide V1.2 For more information on this and other Winmate products, please visit our website at: www.winmate.com Document Part Number: 9152070I1002 Please read these instructions carefully before using this product, and save this manual for future use.
- Page 2 FCC Statement This device complies with part 15 FCC rules. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a class "B"...
- Page 3 Brand and product names are trademarks or registered trademarks of their respective owners. Disclaimer Winmate Inc. reserve the right to make changes, without notice, to any product, including circuits and/or software described or contained in this manual in order to improve design and/or performance. We assume no responsibility or liability...
- Page 4 Customer Service We provide a service guide for any problem by the following steps: First, visit the website of our distributor to find the update information about the product. Second, contact with your distributor, sales representative, or our customer service center for technical support if you need additional assistance. You may need the following information ready before you call: ...
- Page 5 Safety Information WARNING! / AVERTISSEMENT! Always completely disconnect the power cord from your chassis whenever you work with the hardware. Do not make connections while the power is on. Sensitive electronic components can be damaged by sudden power surges. Only experienced electronics personnel should open the PC chassis.
-
Page 6: Table Of Contents
Connecting to Other Devices Power Input Connector Serial Port Connector RJ45 Connector USB A Type Connector Mounting Panel Mounting VESA Mounting Glass Wall Mounting SPECIFICATIONS APPENDIX Appendix A: Cleaning the Monitor Appendix B: Winmate Software Development Kit Winmate Download Center Winmate File Share... -
Page 7: Introduction
Congratulations on purchasing Winmate® 7” S-Series HMI. Interactive and smart automation systems of intelligent buildings are in a fast growing phase. Winmate® multi-touch S-Series HMI is suitable for home automation and room management systems. Flat surface is easy-to-clean and delivers aesthetically pleasing look for any interior. -
Page 8: Package Contents
Package Contents Carefully remove the box and unpack your device. Please check if all the items listed below are inside your package. If any of these items are missing or damaged contact us immediately. Standard factory shipment list: Quick Start Guide Driver CD &... - Page 9 Package may include optional accessories based on your order: VESA Wall Mount VESA Desk Stand VESA Desk Stand Bracket PCVS-V1 LA-100 LA-106 99KK00A0000E 9B0000000128 9B0000000412 Glass Wall Mount Kit Right: PCGM-V1L Left: PCGM-V1L Right: 99KN00A00013 Left:99KN00A00012...
-
Page 10: Product Overview
Product Overview No. Description No. Description ① ⑥ RJ-45 (LAN) 1 Watt Speaker ② ⑦ USB 3.0, USB 2.0 2MP Front Camera (Optional) RGB LED Light Bar ③ ⑧ RS-232/422/485 (W07IB3S-PCM1AC only) ④ ⑨ 12V DC Terminal Block HF RFID Reader (Optional) ⑤... -
Page 11: Getting Started
GETTING STARTED Turning On Your Device Follow the following steps to turn on your device: 1. Connect the AC adapter to the DC-in jack connector on the back side of the HMI device. 2. Connect the power cord to AC adapter. 3. -
Page 12: Operating The Hmi Device
Operating the HMI Device Winmate® 7” S-Series HMI comes with HoT Tab, which allows you to operate the HMI device. Hot Tab Menu To open the Hot Tab menu: 1. Double-click the Hot Tab icon on the Windows desktop. 2. The Hot Tab main menu will appear on the screen as shown below. -
Page 13: Brightness
Brightness Tap Brightness button to show current brightness level. To reduce the brightness, drag by touch this icon to the left. To enhance the brightness, drag by touch this icon to the right. Tap Close icon to save the changes and exit the interface. Volume Tap Volume button to show current brightness level. -
Page 14: Testing Led Light Bar
Testing LED Light Bar Tap Light Bar to access the LED light bar control panel, and select Red / Green / Blue/ Orange color to be displayed on the LED Bar. Performance User can adjust the performance level of the HMI device. There are four options available: ... -
Page 15: Using Front Camera
Using Front Camera Your device might have built-in camera based on your order. Camera Interface Perform one of the following to open the camera: 1. Press the F1 key. 2. Tap then double-tap to display the HotTab screen. Select Camera. Item Description Tap to record videos... -
Page 16: Shooting Photos
Shooting Photos To make a photo: 1. Open the Camera. 2. Focus on the object. 3. Tap to capture the object. 4. By default, the photo preview is displayed briefly on the screen. The preview screen automatically closes after 3 seconds. Alternatively, do one of the following: - Tap to delete the photo and return to the camera screen. -
Page 17: Recording Videos
Recording Videos To record a video: 1. Open the Camera. 2. Focus on the object. 3. Tap to record the video. The video recording screen appears 4. Tap to stop recording and return to the camera screen. 5. To playback the video, browse for the video file and play using a media player application on your device. -
Page 18: Camera Settings
Camera Settings 1. Tap to open the setting page 2. Modify necessary settings. Item Description Check one of the check boxes to show the preview screen right after capturing a photo. • Show Preview: Check this box and enter the preview duration on Close preview after. -
Page 19: Turning Off Your Device
Turning Off Your Device You can Turn OFF the HMI device with the Windows power settings. To shut down the device: 1. Tap Start >Shut down. 2. Wait for your HMI device to completely turn off before disconnecting the power cord (if necessary). -
Page 20: Installation
INSTALLATION Wiring Requirements The following common safety precautions should be observed before installing any electronic device: Strive to use separate, non-intersecting paths to route power and networking wires. If power wiring and device wiring paths must cross make sure the wires are perpendicular at the intersection point. ... -
Page 21: Connecting To Other Devices
Connecting to Other Devices Power Input Connector DC power source input is a 3 pin terminal block connector that supports 12V DC power input. Minimum Voltage 11.4V Maximum Voltage 12.6V Maximum Current 4.2A Voltage Serial Port Connector Use COM1 serial port connector to connect your HMI to external devices such as mouse, modem or printer. -
Page 22: Usb A Type Connector
USB A Type Connector Use USB A Type (USB 2.0) connector to connect your HMI device to other USB2.0 compatible devices. Use USB 3.0 connector to connect your HMI device to other USB 3.0 compatible devices. Pin № Pin № Signal Name Signal Name USB_D-... -
Page 23: Mounting
Mounting S-series HMI devices come with different mounting options suitable for most of the industrial and commercial applications. Panel Mounting Panel / Flush Mounting solution allows installing the HMI device onto the wall. Wall Cutout Screw Hole Diameter 131.4 x 175.4 mm M3x4 mm Mounting Instruction 1. -
Page 24: Vesa Mounting
VESA Mounting VESA Desk Stand PCVS-V1 The HMI device can be installed on a desk with the stand. You can purchase desk stand as an optional accessory. Model Name: PCVS-V1 Part Number: 99KK00A0000E Mounting Instruction Use provided Philips M4x5 screws to fix the desk stand to VESA holes on the back cover of the device. - Page 25 VESA Desk Stand LA-100 The HMI device can be installed on a desk with the stand. You can purchase desk stand as an optional accessory. Model Name: LA-100 Part Number: 9B0000000128 Mounting Instruction Use provided Philips M4x5 screws to fix the desk stand to VESA holes on the back cover of the device.
- Page 26 VESA Wall Mount Bracket LA-106 The HMI device can be installed on a desk with the stand. You can purchase desk stand as an optional accessory. Model Name: LA-106 Part Number: 9B0000000412 Mounting Instruction...
- Page 27 Accessories Dimensions...
-
Page 28: Glass Wall Mounting
Glass Wall Mounting The HMI device can be installed in a glass wall either from right side or from the left. You can purchase Winmate Glass Wall Mount Kit as an optional accessory. Right Side Left Side Model Name: PCGM-V1R... -
Page 29: Specifications
SPECIFICATIONS HMI Device Specifications Model Name W07IB3S-PCM1AC / W07IB3S-PCM1 7” TFT (Widescreen) Size Resolution 1024 x 600 Brightness 500 (typ.) Display Specification Contrast Ratio 700 : 1 (typ.) Viewing Angle -75~75 (H);-70~75(V) Max Colors 16.7M Touch Projected Capacitive Multi-Touch (P-CAP) Intel ®... - Page 30 Power Input 12V DC Power Management Power Consumption Dimensions 189.4 x 145.4 x 37.7 mm (W x L x H) Mechanical Mounting VESA Mount (75 x 75 mm), Panel Mount Specifications Cooling System Fanless design Operating 0°C ~ +55°C Temp. Environmental Humidity 10% ~ 90% (non-condensing, RH)
-
Page 31: Appendix
APPENDIX Appendix A: Cleaning the Monitor Before cleaning: Make sure the device is turned off. Disconnect the power cable from any AC outlet. When cleaning: Never spray or pour any liquid directly on the screen or case. ... -
Page 32: Appendix B: Winmate Software Development Kit
Appendix B: Winmate Software Development Kit Winmate® provides Software Development Kit (SDK). The table below lists SDK provided by Winmate: Item File Type Description Watchdog SDK Digital I/O SDK Watchdog Utility Utility To find the Drivers and SDK, please refer to the Driver CD that comes in the package or contact us. - Page 33 NOTES ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________...
- Page 34 NOTES ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________...
- Page 36 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C Tel: 886-2-8511-0288 Fax: 886-2-8511-0211 Email: sales@winmate.com.tw Official website: www.winmate.com...
