Page 1: User Manual
7"S-Series HMI W07IB3S-PCM1AC (With LED Light Bar) W07IB3S-PCM1 (Without LED Light Bar) Slim-line User Manual Version 1.3 Document Part Number: 9171111I102C... - Page 2 Warranty Winmate Inc. warranty guarantees that each of its products will be free from material and workmanship defects for a period of one year from the invoice date. If the customer...
-
Page 3: Customer Service
Customer Service We provide a service guide for any problem by the following steps: First, visit the website of our distributor to find the update information about the product. Second, contact with your distributor, sales representative, or our customer service center for technical support if you need additional assistance. - Page 4 Advisory Conventions Four types of advisories are used throughout the user manual to provide helpful information or to alert you to the potential for hardware damage or personal injury. These are Notes, Important, Cautions, and Warnings. The following is an example of each type of advisory. NOTE: A note is used to emphasize helpful information IMPORTANT:...
-
Page 5: Safety Information
Safety Information WARNING! / AVERTISSEMENT! Always completely disconnect the power cord from your chassis whenever you work with the hardware. Do not make connections while the power is on. Sensitive electronic components can be damaged by sudden power surges. Only experienced electronics personnel should open the PC chassis. Toujours débrancher le cordon d’alimentation du chassis lorsque vous travaillez sur celui-ci. -
Page 6: Safety Precautions
Safety Precautions For your safety carefully read all the safety instructions before using the device. Keep this user manual for future reference. Always disconnect this equipment from any AC outlet before cleaning. Do not use liquid or spray detergents for cleaning. Use a damp cloth. ... - Page 7 CAUTION/ATTENTION Use the recommended mounting apparatus to avoid risk of injury. Utiliser l’appareil de fixation recommandé pour éliminer le risque de blessure. WARNING! / AVERTISSEMENT! Only use the connection cords that come with the product. When in doubt, please contact the manufacturer. Utiliser seulement les cordons d’alimentation fournis avec le produit.
-
Page 8: Important Information
Important Information Countries/ Area Symbol This equipment complies with essential requirements of: European Union Electromagnetic Compatibility Directive(2014/30/EU) Low Voltage Directive (2014/35/EU) Restrictions of the use of certain hazardous substances (RoHS) Directive (2011/65/EU) FCC Part 15 Subpart B Regulations Class B Federal Communications Commission Radio Frequency Interface Statement This device complies with part 15 FCC rules. - Page 9 European Union This equipment is in conformity with the requirement of the following EU legislations and harmonized standards. Product also complies with the Council directions. Electromagnetic Compatibility Directive (2014/30/EU) EN55024: 2010/ A1: 2015 o IEC61000-4-2: 2009 o IEC61000-4-3: 2006+A1: 2007+A2: 2010 o IEC61000-4-4: 2012 o IEC61000-4-5: 2014 o IEC61000-4-6: 2014...
-
Page 10: About This User Manual
ABOUT THIS USER MANUAL This User Manual provides information about using the Winmate® 7” S-Series HMI with I Intel ® Celeron ® Bay Trail-M N2930 1.83 GHz processor. The documentation set for the 7” S -Series HMI provides information for specific user needs, and includes: ... -
Page 11: Table Of Contents
Contents PREFACE .......................... ii ABOUT THIS USER MANUAL ..................... x CHAPTER 1: INTRODUCTION ..................... 2 1.1 Product Features ..................... 2 1.2 Package Contents ....................3 1.3 Product Overview ....................5 CHAPTER 2: GETTING STARTED ..................7 2.1 Powering On ......................7 2.1.1 AC Adapter Components ................ - Page 12 6.2 Safety Precautions ....................68 6.3 Mounting Guide ....................68 6.3.1 Panel Mounting ..................69 6.3.2 VESA Mounting ................... 70 CHAPTER 7: TECHNICAL SUPPORT ................... 75 7.1 Software Developer Support ................75 7.1.1 Winmate Download Center ................ 75 7.1.2 Winmate File Share ..................75...
- Page 13 7.2 Problem Report Form ................... 76 APPENDIX A: PRODUCT SPECIFICATIONS ................ 78 APPENDIX B: HF RFID READER SPECIFICATIONS .............. 81 xiii...
- Page 14 Introduction This chapter gives you product overview, describes features and hardware specification. You will find all accessories that come with the HMI device in the packing list. Mechanical dimensions and drawings included in this chapter. 7" S-Series HMI...
-
Page 15: Chapter 1: Introduction
1024 x 600 pixel resolution. These models sealed with front IP 65 dust and water proof, and full IP22. The W07IB3S-PCM1AC model supports an exceptional feature - LED light bar. With the help of red, green, blue and orange LED indicators you can see the status of the machine or processes afar. -
Page 16: Package Contents
1.2 Package Contents Carefully remove the box and unpack your HMI device. Please check if all the items listed below are inside your package. If any of these items are missing or damaged contact us immediately. Standard factory shipment list: Quick Start Guide 7”... - Page 17 Package may include optional accessories based on your order: VESA Desk Stand VESA Desk Stand VESA Wall Mount Bracket PCVS-V1 LA-100 LA-106 99KK00A0000E 9B0000000128 9B0000000412 7" S-Series HMI...
-
Page 18: Product Overview
1 Watt Speaker ③ 1 x USB 3.0, 1 x USB 2.0 ⑦ 2MP Front Camera (Optional) ④ HDMI ⑧ RGB LED Light Bar (W07IB3S-PCM1AC only) *RGB LED light bar only available for the model number W07IB3S-PCM1AC 7" S-Series HMI... -
Page 19: Getting Started
Getting Started This chapter tells you important information on power supply, adapter and precautions tips. Pay attention to power considerations. 7" S-Series HMI... -
Page 20: Chapter 2: Getting Started
User Manual Chapter 2 Getting Started CHAPTER 2: GETTING STARTED This chapter provides information on how to connect the HMI device to the source of power, connector pinouts and the guideline to turn on/off the HMI device. 2.1 Powering On 2.1.1 AC Adapter Components Power Cord AC Adapter (12V/ 50W) -
Page 21: Power Considerations
User Manual Chapter 2 Getting Started ALTERNATING CURRENT / MISE À LE TERRE! This product must be grounded. Use only a grounded AC outlet. Install the additional PE ground wire if the local installation regulations require it. *If you do not use a grounded outlet while using the device, you may notice an electrical tingling sensation when the palms of your hands touch the device. -
Page 22: Connecting The Power
User Manual Chapter 2 Getting Started 2.1.3 Connecting the Power Wiring Instruction Connect the AC adapter to the DC-in jack connector on the back side of the HMI device. Connect the power cord to AC adapter. Plug the power cord to the AC outlet and the device will turn on automatically. Note: Power cords vary in appearance by region and country. -
Page 23: Connector Pinouts
User Manual Chapter 2 Getting Started 2.2 Connector Pinouts 2.2.1 Power Connector The DC power source input of the 7” S-Series HMI is a DC-IN jack connector that supports 12V DC power input. Pin № Signal Name Pin № Name DC_IN 2.2.2 COM1 Serial Port Connector The 7”... -
Page 24: Hdmi Connector
User Manual Chapter 2 Getting Started 2.2.4 HDMI Connector The 7” S-Series HMI uses HDMI1.4a connector to connect to the external display. Pin № Signal Name Pin № Signal Name TMDS_DATA2+ TMDS_DATA2- TMDS_DATA1+ TMDS_DATA1- TMDS_DATA0+ TMDS_DATA0- TMDS_CLOCK+ TMDS_CLOCK- DDC_CLOCK DDC_DATA Hot Plug Detect 2.2.5 Ethernet Connector The HMI supports one RJ45 10/100/1000 Mbps Ethernet interface for connecting to the... -
Page 25: Configuring Serial Port Settings
User Manual Chapter 2 Getting Started 2.3 Configuring Serial Port Settings Serial port COM1 can be configured for RS-232, RS-422 or RS-485. Jumpers are located on the motherboard. You need to open the housing in order to access the jumpers. CAUTION/ ATTENTION It is recommended to use factory jumper settings. -
Page 26: Turning On And Off
User Manual Chapter 2 Getting Started 2.4 Turning On and Off The unit is configured to Power ON when is connected to the power source (refer to Ch.2, “Powering On” section of this user manual for more details on how to power on the HMI device). - Page 27 Operating the HMI Device This chapter provides detailed information on how to operate the device. If you have been using touch-screen Panel PCs before, the interface may look familiar. Sections include system settings parameters. 7" S-Series HMI...
-
Page 28: Chapter 3: Operating The Hmi Device
User Manual Chapter 3 Operating the HMI Device CHAPTER 3: OPERATING THE HMI DEVICE In this chapter you will find instructions on how to operate the HMI device with Hot Tab. 3.1 Operating System S-series HMI support several versions of Windows OS: Windows 10 IoT, Windows Embedded 8.1 Industry Pro, Windows Embedded 8 Standard, Windows 7 Pro for Embedded Systems, and Windows Embedded Standard 7 –... -
Page 29: Utilities
User Manual Chapter 3 Operating the HMI Device NOTE: RFID and LED Light Bar are optional features and may not be present in your model. 3.2.2 Utilities Utilities category allows automatically changing orientation from landscape to portrait mode or rotating the desktop to a different degree as 0°, 90°, 180°, and 270°. - Page 30 User Manual Chapter 3 Operating the HMI Device To decrease the volume, drag by touch to the left. To increase the volume, drag by touch to the right. Tap Close to save the changes and exit the interface. 7" S-Series HMI...
-
Page 31: Led Light Bar
User Manual Chapter 3 Operating the HMI Device 3.2.5 LED Light Bar Tap Light Bar to access the LED light bar control panel, and select Red / Green / Blue/ Orange color to be displayed on the LED Bar. 3.2.6 Performance User can adjust the performance level of the HMI device. -
Page 32: Using Front Camera
User Manual Chapter 3 Operating the HMI Device 3.2.8 Using Front Camera Your device might have built-in camera based on your order. NOTE: You camera screen may differ from the pictures in thus user manual. 3.2.8.1 Opening the Camera Perform one of the following to open the camera: •... - Page 33 User Manual Chapter 3 Operating the HMI Device 3.2.8.2 Shooting Photos 1. Open the Camera 2. Focus on the object 3. Tap to capture the object 4. By default, the photo preview is displayed briefly on the screen The preview screen automatically closes after 3 seconds. Alternatively, do one of the following: - Tap to delete the photo and return to the camera screen...
- Page 34 User Manual Chapter 3 Operating the HMI Device 5. To playback the video, browse for the video file and play using a media player application on your device 3.2.8.4 Camera Settings 1. Tap to open the setting page 2. Modify necessary settings. Item Description Check one of the check boxes to show the...
-
Page 35: Using Hf Rfid Reader
User Manual Chapter 3 Operating the HMI Device 3.3 Using HF RFID Reader Notice that HF RFID Reader is an optional feature for 7” S-Series HMI and may not be present in your device. HF RFID is commonly used for ticketing, payment, and data transfer applications. The RFID Reader is located on the bottom right front side of the HMI device. -
Page 36: Reading Mode
User Manual Chapter 3 Operating the HMI Device 3.3.1 Reading Mode Select the default RFID Reader COM14or press Search on the upper left corner of the screen. The system will automatically find RFID COM port, show the Version. Item № Key button Function E1- Version... -
Page 37: Writing Mode
User Manual Chapter 3 Operating the HMI Device Item № Data 32 Function XXXXXXXXXXXABCDEF Display the information written in the card 3.3.2 Writing Mode Refer to the RFID Porting Guide SDK to configure Writing Mode parameters. 7" S-Series HMI... -
Page 38: How To Enable Watchdog
Operating the HMI Device 3.4 How to Enable Watchdog To enable Watchdog, you need to download Winmate Watchdog utility. Find more information on Watchdog in “Watchdog Guide” that you can download from Winmate Download Center or File Share. Refer to the Ch.7, “Technical Support”... -
Page 39: Driver Installation
Driver Installation This chapter describes how to install all necessary drivers. 7" S-Series HMI... -
Page 40: Chapter 4: Driver Instalation
7" S-Series HMI Chapter 4 Driver Installation CHAPTER 4: DRIVER INSTALATION This chapter provides guideline to driver installations. 4.1 Installing Chipset Driver Step 1 Insert the CD that comes with the motherboard. Open the file document “Chipset Driver” and click “infinst_auto.exe” to install driver. Step 2 Click Next to continue. - Page 41 7" S-Series HMI Chapter 4 Driver Installation Step 3 Click Yes to agree the license terms. Step 4 Click Next to install the driver. Step 5 Software setup progress window will appear, click Next to continue. Step 6 Click “Yes, I want to restart this computer now” to finish the installation. 7"...
-
Page 42: Installing Graphics Driver
7" S-Series HMI Chapter 4 Driver Installation 4.2 Installing Graphics Driver Step 1 Insert the CD that comes with the motherboard. Open the file document “Graphics Driver” and click Setup to execute the setup. Step 2 Setup Welcome Window will appear, click Next to continue the process. Step 3 Carefully read the license terms and click Yes to agree. -
Page 43: Installing Intel Sideband Fabric Device (Intel Mbi) Driver (Windows 8)
7" S-Series HMI Chapter 4 Driver Installation 4.3 Installing Intel Sideband Fabric Device (Intel MBI) Driver (Windows 8) Step 1 Insert the CD that comes with the motherboard. Open the file document “MBI” and click “Setup.exe” to install the driver. Step 2 Welcome to the setup program window will appear, click Next to start the installation. -
Page 44: Installing Intel Trusted Engine Interface (Intel Txe) Driver
7" S-Series HMI Chapter 4 Driver Installation 4.4 Installing Intel Trusted Engine Interface (Intel TXE) Driver Step 1 Insert the CD that comes with the motherboard. Open the file document “TXE” and click “Setup TXE.exe” to install the driver. Step 2 Welcome to the setup program window will appear, click Next to start the installation. -
Page 45: Installing Intel Network Connections
7" S-Series HMI Chapter 4 Driver Installation 4.5 Installing Intel Network Connections User must confirm the type of operating system is being used before installing Intel Network Connections. Follow the steps below to complete the installation. Step 1 Click “PROWin64.exe” Step 2 Click Yes to start the installation. -
Page 46: Installing Audio Driver
7" S-Series HMI Chapter 4 Driver Installation 4.6 Installing Audio Driver The ALC886 series are high-performance 7.1+2 channel high definition audio codecs that provide ten DAC channels for simultaneous support of 7.1 sound playback, plus 2 channels of independent stereo sound output (multiple streaming) through the front panel stereo outputs. -
Page 47: Installing Usb 3.0 Driver (Windows 7)
7" S-Series HMI Chapter 4 Driver Installation 4.7 Installing USB 3.0 Driver (Windows 7) This HMI features Intel Celeron Trail-M N2930 CPU with the Intel® USB 3.0 extensible Host Controller. You need to install the Intel® USB 3.0 extensible Host Controller driver to enable the function. -
Page 48: Bios Setup
BIOS Setup BIOS Setup Utility is a program for configuration basic Input / Output system settings of the HMI for optimum use. This chapter provides information on how to use BIOS setup, its functions and menu. 7" S-Series HMI... -
Page 49: Chapter 5: Bios Setup
User Manual Chapter 5 BIOS Setup CHAPTER 5: BIOS SETUP 5.1 When and How to Use BIOS Setup To enter the BIOS setup, you need to connect an external USB keyboard, press <Del> key when the prompt appears on the screen during start up. The prompt screen shows only few seconds, you need to press <Del>... -
Page 50: Main Menu
User Manual Chapter 5 BIOS Setup Exit Change Opt. Enter Select or execute command Cursor ↑ Moves to the previous item Cursor ↓ Goes to the next item Cursor ← Moves to the previous item Cursor → Goes to the next item NOTE: You can press the F1, F2, F3, F4, –/+, and Esc keys by connecting a USB keyboard to your device. -
Page 51: Advanced Menu
User Manual Chapter 5 BIOS Setup BIOS Description Setting Option Effect Setting System Displays the system Adjustment of the Set the language in Language language. [English] is language other language. The set up by default. language in this device is English. System This is current date Date and time... - Page 52 User Manual Chapter 5 BIOS Setup BIOS Setting Description Setting Option Effect ACPI Settings Configures ACPI settings Enter Opens submenu F81866 Super IO Configures IO settings Enter Opens Configuration submenu Hardware Monitor Configures Hardware Monitor Enter Opens settings submenu S5 RTC Wake Settings Configures RTC Wake Enter Opens parameters...
- Page 53 User Manual Chapter 5 BIOS Setup For items marked ► press <Enter> for more options. 5.2.2.1 ACPI Settings Advanced Configuration and Power Interface (ACPI) settings allow to control how the power switch operates. The power supply can be adjusted for power requirements. You can use the screen to select options of ACPI configuration.
- Page 54 User Manual Chapter 5 BIOS Setup 5.2.2.2 F81866 Super IO Configuration You can use the screen to select options for Super IO Configuration, and change the value of the option selected. A description of the selected item appears on the right side of the screen.
- Page 55 User Manual Chapter 5 BIOS Setup GPI0 Port Configuration You can use the screen to change GPI0 Port setting. Use these items to set parameters related to PIN3-PIN14 Control. 5.2.2.3 Hardware Monitor You can check PC Health Status parameters such as system temperature, fan speed etc. 7"...
- Page 56 User Manual Chapter 5 BIOS Setup 5.2.2.4 S5 RTC Wake Settings Wake system from S5 enables or disables system wake on alarm event. It allows you to wake up the system in a certain time. Wake System from S5 with fixed time setting Select Fixed Time to set the system to wake on the specified time.
- Page 57 User Manual Chapter 5 BIOS Setup Wake system from S5 after dynamic time setting Select Dynamic Time to set the system to wake on the current time + increase minute (s). 7" S-Series HMI...
- Page 58 User Manual Chapter 5 BIOS Setup 5.2.2.5 CPU Configuration BIOS Setting Description Setting Effect Option Socket CPU This item contains socket Enter Open sub-menu Information specific CPU information. CPU Thermal Thermal control Enter Open sub-menu Configuration Limit CPUID Limits CPIID Maximum Disabled/E Enable/Disable Maximum...
- Page 59 User Manual Chapter 5 BIOS Setup 5.2.2.6 Configuration BIOS Setting Description Setting Effect Option CPU C State Shows CPU C State Report Enabled/ Enable or Disable CPU Report Disabled C state report to OS Max CPU C- Allows to enter power- C1E, C3, Enable or Disable CPU State...
- Page 60 User Manual Chapter 5 BIOS Setup 5.2.2.7 Thermal Configuration This menu allows controlling thermal settings of the computer. Refer to the descriptions on the top right side of the screen for detailed information about each setting. BIOS Description Setting Option Effect Setting Critical...
- Page 61 User Manual Chapter 5 BIOS Setup 5.2.2.8 IDE Configuration BIOS Setting Description Setting Effect Option Serial- ATA Responsible for Enabled/ Enable or disable this (SATA) supporting chipset Disabled function drives with SATA interface. SATA Speed Allows forcing the speed Gen1 The maximum speed will be Support limit SATA II ports...
- Page 63 User Manual Chapter 5 BIOS Setup SATA Mode This option specifies the [AHCI] Selecting this option allows operation mode of you to take full advantage of modern IDE / SATA- the extended host controller controller chipset SATA II [IDE] SATA controller will operate in a mechanism similar to a conventional IDE-controller [RAID]...
- Page 64 User Manual Chapter 5 BIOS Setup 5.2.2.9 Miscellaneous Configuration OS Selection This item allows users to select the proper Operating System. BIOS Setting Description Setting Effect Option Windows 8.X Allows user to choose the Enter Use Windows 8.X proper OS. Windows 7 Allows user to choose the Enter...
- Page 65 User Manual Chapter 5 BIOS Setup 5.2.2.10 CSM Configuration BIOS Setting Description Setting Effect Option CSM Support The Compatibility Support Module Enabled/ Enable or disable (CSM) is a component of the UEFI Disabled the Compatibility firmware that provides legacy Support Module BIOS compatibility by emulating a BIOS environment, allowing legacy operating systems and some...
- Page 67 User Manual Chapter 5 BIOS Setup Video Specifies which Video option ROM UEFI Only UEFI option is booted ROMs are booted Legacy Only Legacy option ROMs are booted Other PCI Specifies which option ROM is UEFI Only UEFI option Devices booted for devices other than the ROMs are booted network, storage or video...
- Page 69 User Manual Chapter 5 BIOS Setup XHCI Hand‐off This is a workaround for OSs Disable Disables this function without XHCI hand‐ off support. Enable Enables this function EHCI Hand‐off This is a workaround for OSs Disable Disables this function without ECHI hand‐ off Enable Enables this function support.
- Page 70 User Manual Chapter 5 BIOS Setup 5.2.2.12 Platform Trust Technology BIOS Setting Description Setting Option Effect fTPM Trusted Platform Module Enabled/Disabled Enables or parameters disables this function 7" S-Series HMI...
- Page 71 User Manual Chapter 5 BIOS Setup 5.2.2.13 Security Configuration BIOS Setting Description Setting Effect Option Trusted Execution Technology Enabled/D Enables or disables this parameters isabled function TXE HMRFPO TXE HMRFPO parameters Enabled/D Enables or disables this isabled function TXE Firmware TXE Firmware Update Enabled/D Enables or disables this...
-
Page 72: Chipset Menu
User Manual Chapter 5 BIOS Setup 5.2.3 Chipset Menu For items marked with ►, please press <Enter> for more options. BIOS Description Setting Effect Setting Option High Allow to set up High Precious Timer Enabled/ Enables/Disable Precious settings Disabled s this function Timer Restore AC This function allows to set up... -
Page 73: Security Menu
User Manual Chapter 5 BIOS Setup 5.2.4 Security Menu In the Security menu, users can set administrator password, user password, and HDD security configuration. BIOS Setting Description Setting Effect Option Administrator Displays whether or not an Enter Enter Password administrator password has been password set. -
Page 74: Boot Configuration
User Manual Chapter 5 BIOS Setup 5.2.5 Boot Configuration The Boot menu sets the sequence of the devices to be searched for the operating system. The bootable devices will be automatically detected during POST and shown here, allowing you to set the sequence that the BIOS uses to look for a boot device from which to load the operating system. - Page 75 User Manual Chapter 5 BIOS Setup Fast Boot Enables or disables Fast Boot to Disabled Disables this shorten the OS boot process. function (Default: Disabled). Enabled Enables this function Boot Mode Specifies which mode will be used Legacy Only Legacy option Select for booting is booted...
-
Page 76: Save & Exit
User Manual Chapter 5 BIOS Setup 5.2.6 Save & Exit The Exit menu displays a way how to exit BIOS Setup utility. After finishing your settings, you must save and exit for changes to be applied. BIOS Setting Description Setting Effect Option Save... - Page 77 User Manual Chapter 5 BIOS Setup Discard Reset system setup without Enter Saves the changes Changes and saving any changes <YES> Reset Enter <NO> Return to the BIOS Setup Main Menu Save Save changes done so far to any Enter Saves the changes Changes of the setup options.
-
Page 78: Using Recovery Wizard To Restore Computer
User Manual Chapter 5 BIOS Setup 5.3 Using Recovery Wizard to Restore Computer Note: Before starting the recovery process, make sure to backup all user data. The data will be lost after the recovery process. To enable quick one-key recovery procedure: ... - Page 79 Mounting Solutions This chapter provides step-by-step mounting guide for all available mounting options. 7" S-Series HMI...
-
Page 80: Chapter 6: Mounting
User Manual Chapter 6 Mounting Solutions CHAPTER 6: MOUNTING This chapter provides mounting guide for all available mounting options. Pay attention to cautions and warning to avoid any damages. WARNING! / AVERTISSEMENT! Follow mounting instructions and use recommended mounting hardware to avoid the risk of injury. -
Page 81: Safety Precautions
User Manual Chapter 6 Mounting Solutions 6.2 Safety Precautions Observe the following common safety precautions before installing any electronic device: • Use separate, non-intersecting paths to route power and networking wires. If power wiring and device wiring paths must be crossed make sure the wires are perpendicular at the intersection point. -
Page 82: Panel Mounting
User Manual Chapter 6 Mounting Solutions 6.3.1 Panel Mounting Panel Mount mounting solutions is suitable for many applications where HMI should be embedded in the machine. With this mounting solution flat surface leave no bezel in the front. Wall Cutout Screw Hole Diameter 131.4 x 175.4 mm M3 x 4mm... -
Page 83: Vesa Mounting
User Manual Chapter 6 Mounting Solutions 6.3.2 VESA Mounting 6.3.2.1 VESA Desk Stand PCVS-V1 The HMI device can be installed on a desk with the stand. You can purchase desk stand as an optional accessory. Model Name: PCVS-V1 Part Number: 99KK00A0000E Mounting Instruction ... - Page 84 User Manual Chapter 6 Mounting Solutions 6.3.2.2 VESA Desk Stand LA-100 The HMI device can be installed on a desk with the stand. You can purchase desk stand as an optional accessory. Model Name: LA-100 Part Number: 9B0000000128 Mounting Instruction ...
- Page 85 User Manual Chapter 6 Mounting Solutions 6.3.2.3 VESA Wall Mount Bracket LA-106 The HMI device can be installed on a desk with the stand. You can purchase desk stand as an optional accessory. Model Name: LA-106 Part Number: 9B0000000412 Mounting Instruction 7"...
- Page 86 User Manual Chapter 6 Mounting Solutions Accessories Dimensions 7" S-Series HMI...
-
Page 87: Technical Support
Technical Support This chapter includes directory to Winmate technical support. 7" S-Series HMI... -
Page 88: Chapter 7: Technical Support
This chapter includes technical support documents and software developing kit (SDK). If any problem occurs fill in problem report form enclosed and immediately contact us. 7.1 Software Developer Support Winmate provides the following SDK and Utilities for -Series HMI with 1.83GHz Intel® Celeron® N2930: Item File Type Description... - Page 89 7" S-Series HMI Chapter 7 Technical Support 7.2 Problem Report Form 7" S-Series HMI (Slim-line) Customer name: Company: Tel.: Fax: E-mail: Date: Product Serial Number: _____________________________________________________ Problem Description: Please describe the problem as clearly as possible. Detailed description of the occurred problem will allow us to find the best solution to solve the problem as soon as possible.
-
Page 90: Product Specifications
Product Specifications This section includes product specifications. Appendix 7" S-Series HMI... - Page 91 User Manual Appendix A Product Specifications APPENDIX A: PRODUCT SPECIFICATIONS HMI Device Model Name W07IB3S-PCM1AC/ W07IB3S-PCM1 Size 7" TFT (widescreen) Resolution 1024 x 600 Brightness ( ) 500 cd/m (typ.) Display Contrast Ratio 700:1 (typ.) Specifications Viewing Angle -75~75 (H);-70~75(V)
- Page 92 User Manual Appendix A Product Specifications Power Input 12V DC-in Power Power Management Consumption Dimensions 189.4 x 145.4 x 37.7 (mm) (W x L x H) Mechanical Mounting VESA Mount (75 x 75mm) Specifications Cooling System Fanless design Operating Temp. 0 °C to +50 °C Environmental Humidity...
- Page 93 HF RFID Reader Specifications This section includes the HF RFID Reader specifications. Appendix 7" S-Series HMI...
- Page 94 User Manual Appendix B HF RFID Reader Specifications APPENDIX B: HF RFID READER SPECIFICATIONS This section includes the HF RFID Reader specifications. The RFID Reader can read and write data according to different HF RFID standards. HF RFID Standard Purpose Standard for MIFARE technology, which used in smart ISO-14443 A cards and proximity cards...
- Page 95 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C Tel: 886-2-8511-0288 Fax: 886-2-8511-0211 Email: sales@winmate.com.tw Official website: www.winmate.com...
