A
Specifications
10/100/1000BASE-T Cable Specifications
Port Type
10BASE-T
100/BASE-T and
1000BASE-T
NOTE: 1000BASE-T signaling requires four twisted pairs of Category 5
balanced cabling, as specified in ISO/IEC 11801:1995 and ANSI/EIA/TIA-
568-A (1995) and tested for additional performance using testing procedures
defined in TIA/EIA TSB95.

Performance Specifications

Feature
PCI clock
PCI Data/Address
PCI data burst transfer rate
PCI modes
10/100/1000BASE-T

Physical Characteristics

Dimension
Length
Width

Power Requirements

Specification
Operating voltage
Power consumption
Connector Media
RJ-45 Cat. 3, 4, 5, or 5e UTP
RJ-45 Cat. 5/Cat. 5e UTP
Specification
66 MHz max
32 bit
132 MBps 32-bit/33 MHz
264 MBps 32-bit/66 MHz
Master/slave
10/100/1000 Mbps (full duplex)
Measurement
12 cm (4.75 in)
5 cm (2.0 in)
Measurement
+5V ± 5%
3 Watts .6A @ +5VDC
Maximum Distance
100 meters (328 ft)
100 meters (328 ft)
45
