3Com 3C2000 User Manual page 19

Maximum Frame Size
Media Type
Network Address
Number of Receive Buffers
Number of Transmit Buffers
Wake up Capabilities
7 When configuration is complete, click OK to accept the settings.
8 Reloading your driver is recommended. To do so:
a Right-click My Network Places.
b Right-click the NIC and select Disable.
The driver is unloaded.
c Right-click the NIC and select Enable.
The driver is reloaded.
9 Verify that the NIC port LEDs operate as described in the table in "Checking Port
LEDs" on page 43.
Modifying Configuration Parameters
• 1514
• 64 - 9014 (range)
• 10 Mb, Full Duplex
• 10 Mb, Half Duplex
• 100 Mb, Full Duplex
• 100 Mb, Half Duplex
• 1000 Mb, Full Duplex
• Auto
• Value:
• Not Present
• 50
• 3 - 500 (range)
• 50
• 4 - 200 (range)
• Both
• Magic Packet
• None
• Wake Up Frame
15
