4 Windows 2000 Driver Installation
14
Modifying Configuration Parameters
Although the default values should be appropriate in most cases, you may change any
of the available options to meet the requirements of your specific system:
1 On the Windows Desktop, right-click the My Computer icon and select Properties
from the pop-up menu.
The System Properties window appears.
2 Click the Hardware tab and then click Device Manager.
The Device Manager window appears.
3 Scroll down the list of hardware devices to Network Adapters. Click the plus sign
(+) to the left of the icon to display the list of NICs currently configured.
4 Double-click the Gigabit Ethernet NIC you want to configure.
The Gigabit Ethernet Properties window appears, showing the General tab.
5 Click the Advanced tab.
A window showing the list of configuration parameters (and default values) for the
NIC appears.
6 Change the parameters as desired.
Click the options listed under Properties and then use the pull-down window under
Value to change the default or assigned value.
The following parameters are available (default values are listed in bold).
NOTE: These parameters and options are subject to change and may vary
from those listed in this user guide.
Parameter
802.1p Support:
FlowControl
Hardware Checksumming
Interrupt Moderation
Log Status Messages
Max IRQ per Sec
Option(s)
• Disable
• Enable
• Asymmetrical and Symmetrical
• Asymmetrical Flow Control
• No Flow Control
• Symmetrical Flow Control
• Off
• On
• Off
• On
• All Messages
• Errors
• None
• Status Messages
• Warnings
• 5000
• 1000 - 30000 (range)
