6.2

REACH AND TRAJECTORY

Tables and graphs in this section give the stream trajectory for the Master-Force nozzle at various flows.
Notes on trajectory graphs:
• Graphs show approximate effective stream trajectory at 30 degrees elevation in no wind conditions. Distance to last water drops
approximately 10% farther.
• To estimate trajectories at elevations other than 30 degrees, refer to document LTT-135, available at tft.com.
• Trajectories shown are for water. The addition of foam is expected to decrease the reach by 10%.
• Tail or head winds of 20 MPH (30 KPH) may increase or decrease the range approximately 30%.
m
©Copyright Task Force Tips LLC 2020
CURVE
GPM
LBS
FLOW
REACTION
A
300
160
B
400
210
C
500
260
D
600
320
E
700
370
F
800
420
CURVE
GPM
LBS
FLOW
REACTION
A
300
60
B
400
140
C
500
185
D
600
225
E
700
300
F
800
385
Figure 6.1A
CURVE
L/min
FLOW
A
1100
B
1500
C
2000
D
2300
E
2700
F
3000
CURVE
L/min
FLOW
A
1100
B
1500
C
2000
D
2300
E
2700
F
3000
9
KGF
REACTION
70
95
120
145
170
190
KGF
REACTION
30
65
85
100
140
175
LIM-027 December 15, 2020 Rev00
