4 C 1: I
HAPTER NSTALLING THE
I J
NTELLI ACK
Component Purpose
Single-port For providing Power Over Ethernet to locally
Ethernet power power a single IntelliJack.
supply
Local power For locally powering a single IntelliJack;
supply required if your network does not support
Power Over Ethernet.
NBX Phone For powering over Ethernet a NBX VoIP
Power Module telephone that uses Capacitive Power
Discovery Process by an IEEE 802.3af compliant
PSE.
Mounting Plates and Spacers
3Com Part Number:
Description:
10mm-thick extension ring that attaches to the back of an NJ225 IntelliJack extension ring
that ships with every unit, effectively extending the depth of the wall space. This allows
flush mounting of an IntelliJack in a shallow DIN or BSI cutout.
3Com Part Number:
Description:
Mounting plate used to securely install an NJ225 IntelliJack in wall openings with built-in
trim rings, as found in Spain and other locations.
3CNJMP-EXT
IntelliJack NJ225 10mm extension ring
3CNJMP-SPR
IntelliJack NJ225 trim ring spacer
3C Number(s)
3CNJPSE
3CNJPSL
3CNJVOIP-NBX
