Draper FlexShade ZIP 92 Instructions Manual

FlexShade ZIP 92 & ZIP 127
®
Exterior shading system, ZIP detail creates weather/shading barrier
protects against wind, sun, snow, and insects to maintain a comfortable space

Overview - Components

E N D
C A
P
SIDE
CHANNEL
Contents
Overview - Components .......................................................................................1
PLEASE READ - Important Safety and Installation Information ....................2
PLEASE READ - Cleaning and Maintenance .....................................................2
Section 1 - Site Preparation ................................................................................3
Section 2 - Curved or Square Headbox Mounting ..........................................3
Section 3 - Attaching Mounting Brackets to Headbox ...................................4
Section 4 - Direct Mounting to Ceiling or Wall .................................................4
Section 5 - Installing Side Channels ..................................................................5
Section 6 - Mounting Angled Headbox ..............................................................6
Section 7 - Mounting Headbox in a Recessed Pocket ....................................6
Section 8 - Mounting Side Channels Into a Recessed Pocket ......................7
SIDE
CHANNEL
Scan code with your
smartphone to view a playlist
of FlexShade ZIP installation
®
videos. These videos do not
replace the written instructions,
but offer valuable help.
Section 9 - Channel Adaptors .............................................................................7
Section 10 - Anti-Insect Brush Seals .................................................................7
Section 11 - Limit Setting: RTS Obstacle Detection Motors ..........................8
Section 12 - Limit Setting: Standard and Quiet Motors ..................................9
Section 13 - Complete Electrical Connection ..................................................9
Section 14 - Cable Exit ........................................................................................10
Section 15 - Hem Bar Liner ................................................................................10
Section 16 - Assembled Dimensions: Front View ..........................................11
Section 17 - Assembled Dimensions: Side View ............................................11
Section 18 - Component Dimensions ..............................................................12
If you have any difficulties installing or servicing your
Draper, Inc. | 411 S. Pearl St. Spiceland, IN 47385
INSTRUCTIONS
INSTALLATION & OPERATION
PERSONNEL REQUIRED
1 2
TOOLS REQUIRED
PENCIL TAPE MEASURE
LASER LEVEL LEVEL
POWER DRILL
WIRE STRIPPERS
PLIERS
HARDWARE
(by others)
CRIMPING TOOL
HEX WRENCH
CAUTION
Read and understand
all warnings before
beginning installation.
FlexShade ZIP, call your dealer or Draper, Inc.
draperinc.com | 765.987.7999 | 800.238.7999
|
© 2020 All Rights Reserved FORM: FS_ZIP_Inst20
