EDWARDS SYSTEMS TECHNOLOGY EST2 Operation Manual page 85

Fire Alarm Control Panel Operating Instructions
Installed By:
Per NFPA Standard:
72, Ch 3 - Local
72, Ch 4 - Auxiliary
72, Ch 4 - Remote Sta.
72, Ch 4 - Proprietary
72, Ch 4 - Central Sta.
Dated:
For Service Contact:
Inspected By:
Date:
Power Supply:
Primary
Location
Fuses
Secondary
Type
Specs.
Figure A-1: Fire alarm control panel operating instructions
EST2 System Operations Manual
Location:
Normal Condition: The Power LED (green) is on. All other LEDs are off.
Alarm Condition: The Alarm LED (red) turns on, the display shows the alarm location
and zone, and the internal buzzer pulses.
To view other alarm messages: Press the ALARM review switch (down arrow).
To silence audible devices: Press the Alarm Silence switch.
To reset the system: Find the cause of the alarm condition, correct it, and press the
Reset switch.
Note: Each new alarm will resound the audible devices, but you cannot resound
them by pressing the Alarm Silence switch a second time.
Supervisory Condition: The Supervisory LED (yellow) turns on, the display shows the
supervisory condition, location, and zone, and the internal buzzer pulses.
To view other supervisory messages: Press the SUPVR review switch (down arrow).
To silence buzzer: Press Local Silence switch.
To clear the system: Find
the Reset switch.
Trouble Condition: The system Trouble LED (yellow) turns on, the display shows the
trouble location and zone, and the internal buzzer pulses.
To view other trouble messages: Press the TRBLE review switch (down arrow).
To silence the buzzer: Press the Local Silence switch.
To clear the system: Find the cause of the trouble and correct it. The system
automatically clears itself upon correction of trouble condition.
Monitor Condition: The Monitor LED (yellow) turns on, the display shows monitor
conditions, and the internal buzzer pulses during a non-fire alarm condition.
To view other monitor conditions: Press the MONTR review switch ( down arrow).
To clear system: The system automatically clears itself upon restoration of monitor
condition.
Fire Drill: Notify the fire department before you run the test. All audible and visual
notification appliances will operate during a drill.
To drill all notification appliances: Press the Drill switch.
To end the drill: Press the Drill switch a second time, or press Alarm Silence.
Frame these instructions and mount them next to the fire alarm control panel. For
additional information, See the
the cause of supervisory condition, correct it, and p
System Operations Manual .
Operator instructions
ress
STDOP007.CDR
A.3
