Checking System Status; Viewing The General Status Screen - EDWARDS SYSTEMS TECHNOLOGY EST2 Operation Manual

Operating panel devices

Checking system status

Status Legend
AC Power
Ground Fault
Battery
Remote Annunciator
2.16
This section explains the functions of the Status switch. In the
Status mode, the 2-LCD displays the following screens:
• General Status
• Loop 1 Status
• Loop 2 Status
• Field Panel Status (if conditions exist)
• Relay/LED Status (if conditions exist)
• Disabled Components/Functions (if conditions exist)
For a detailed explanation about the parameters of keypad
Note:
entries, see Making keypad entries, earlier in this chapter.
To access the system status menu:
1. At the 2-LCD, press Status.
2. Enter a level 1, 2, or 3 password.
3. Make the appropriate selection based on the screen in Figure
2-4.
Status Report
[ent] key scrolls.
[del] key terminates
Revision X.XX
Figure 2-4: System status menu

Viewing the general status screen

To view the general status screen:
1. At the 2-LCD, press Status.
2. Enter a level 1, 2, or 3 password.
3. Press Enter until you see the general status screen (Figure
2-5).
Status: (1=Fault)
ACp0 Bat0 MPw0
Gnd0 Ann0 Prn0
Figure 2-5: General status screen
STDOP021.CDR
STDOP004.CDR
485 Comm. Status
SPw0
Smoke Power
Dia0
Dialer
NAC Power
Printer/External Command Port
EST2 System Operations Manual
