Selecting System Functions On The 2-Lcd - EDWARDS SYSTEMS TECHNOLOGY EST2 Operation Manual

Table 2-5: Function switches
Function Switch
Status
Program
Enable
Disable
Activate
Restore
Reports
Test
EST2 System Operations Manual
The operator also needs to know parameters for other keypad
entries, where:
• yyyy = year
• mm = month
• dd = day
• 01 - 07 = day of week
• hh = hour
• mm = minute
• ss = second
• nnnn = password, action number, sequence number
• tttt = time control
• PP = Priority
Do not confuse a priority (PP) with the panel address (pp).
Note:

Selecting system functions on the 2-LCD

Description
When pressed, the Status switch displays menus for viewing the status of
the general panel, the Signature Data Circuit (SDC), relays, LEDs, and
disabled devices.
When pressed, the Program switch displays menus for setting the time
and date, setting user passwords, configuring the RS-485 port, restarting
the system, and autoprogramming.
When pressed, the Enable switch displays menus for enabling the
following system components: zones, zone messages, time controls, data
line, panels, actions, sequences, laptop, mapping.
When pressed, the Disable switch displays menus for disabling the
following system components: zones, zone messages, time controls, data
line, panels, actions, sequences, laptop, mapping.
When pressed, the Activate switch displays menus for activating the
following system components: output devices, actions, sequences,
primary smoke sensitivity levels, and alternate smoke sensitivity levels.
When pressed, the Restore switch displays menus for returning the
following system components to the restored state: output devices,
actions, and sequences.
When pressed, the Reports switch displays menus for obtaining system
sensitivity and history reports. Reports may be viewed on the main
controller display or sent to a printer.
When pressed, the Test switch activates the walk test function for testing
individual initiating device circuits.
Operating panel devices
2.7
