Table 2-2: Control switches
Control Switch
Alarm Silence
Drill
User Defined
Table 2-3: Message review switches
Message Description
Switch
ALARM Press the down arrow to scroll from the first alarm message to the last one.
Press the up arrow to scroll from last alarm message to the first one.
Press both arrows simultaneously to jump to the first message.
SUPVR Press the down arrow to scroll from the first supervisory message to the last one.
Press the up arrow to scroll from last supervisory message to the first one.
Press both arrows simultaneously to jump to the first message.
TRBLE Press the down arrow to scroll from the first trouble message to the last one.
Press the up arrow to scroll from last trouble message to the first one.
Press both arrows simultaneously to jump to the first message.
MONTR Press the down arrow to scroll from the first monitor message to the last one.
Press the up arrow to scroll from last monitor message to the first one.
Press both arrows simultaneously to jump to the first message.
EST2 System Operations Manual
Description
When pressed, the Alarm Silence switch turns off all audibles or visuals
as defined in the 2-SDU. The Alarm Silence switch also features an
integral LED. When lit, the LED indicates that the notification appliances
are off. When flashing, the LED indicates that the Alarm Silence switch is
inhibited.
Silence inhibit (check one): __none
When pressed, the Drill switch activates all audibles or visuals as defined
in the 2-SDU. Drill switch also features an integral LED. When lit, the LED
indicates that the Drill mode is on.
Site-specific programmed option. This switch will activate:
Enter the rule label:
The User-defined switch permits the operator to activate an action by
pressing it. The programmer determines the function of the User-defined
switch and enters it in the 2-SDU. See the 2-SDU Help for details on
programming user-defined switch.

Scrolling message review switches

The operator must press the Local Silence switch to
Note:
review messages on the 2-LCD. Messages are listed with the
first (most recent) at the top of the queue and the last (oldest) at
the bottom.
Operating panel devices
__1 minute __3 minutes
2.5
