Viewing The Loop Status Screens - EDWARDS SYSTEMS TECHNOLOGY EST2 Operation Manual

Circuit ID
Communications
Programming
Circuit Reset
Circuit Ground Fault
Figure 2-6: Loop status screen
EST2 System Operations Manual
"0" indicates a normal condition for the associated parameter;
"1" indicates a fault.
Table 2-6: General status legend
Legend Cause
ACp AC Power
Gnd Ground Fault
Bat Battery
Ann Remote Annunciator
MPw NAC Power
Prn Printer
Spw Smoke Power
Dia Dialer

Viewing the loop status screens

To view the loop status screens:
1. At the 2-LCD, press Status.
2. Enter a level 1, 2, or 3 password.
3. Press Enter until you see the loop 1 status screen (Figure
2-6).
4. Press Enter one more time to see the loop 2 status screen.
The loop 2 status screen displays the same items as the loop 1
status window.
Loop 1 status:
1= flt/act, 0=ok/inact.
Res0 Bal0
Com0
Prg0 Gnd0 Lin0
"0" indicates a normal condition for the associated parameter;
"1" indicates a fault.
Operating panel devices
STDOP005.CDR
Status Legend
Mpg0
Mapping in Progress
Map0
Map Fault
Balanced Map
Class A Line Fault
2.17
