Viewing history reports

To view a history report:
1. At the 2-LCD, press Reports.
2. Enter a level 1, 2, or 3 password.
3. Enter 2 to choose a history report.
4. Enter 1 to send the report to the 2-LCD display.
The 2-LCD will display the screens in Figure 2-18 and Figure
2-19.
Comp. Rev: X.Y
Proj Rev M.N
Last updated on:
01/03/99 01:01:01
Figure 2-18: History report revision
Press:
[MONTR ] for older
[MONTR ] for newer
[DEL] to terminate
Figure 2-19: History report instructions
Figure 2-20 illustrates two typical history reports on the 2-LCD.
01/03/99
A XXXXXXXXXXXXXXXX: ppaa
Response Msg Line 1
Response Msg Line 2
01/03/99
R XXXXXXXXXXXXXXXX: ppaa
Response Msg Line 1
Response Msg Line 2
Figure 2-20: Typical history reports on the 2-LCD
STDOP030.CDR
STDOP031.CDR
01:01
A: Active
01:01
R: Restore
STDOP032.CDR
