User Guide | Controller for SemiPlugin appliance, AK-CC 460
Fault message
In an error situation the LED's on the front will flash and the alarm relay will be activated. If you push the top button in this situation you can see the
alarm report in the display.
There are two kinds of error reports - it can either be an alarm occurring during the daily operation, or there may be a defect in the installation.
A-alarms will not become visible until the set time delay has expired.
E-alarms, on the other hand, will become visible the moment the error occurs.
(An A alarm will not be visible as long as there is an active E alarm).
Here are the messages that may appear:
Code / Alarm text via data
communication
A1/--- High t.alarm
A2/--- Low t. alarm
A4/--- Door alarm
A5/--- Max hold time
A13/--- High temp S6
A14/--- Low temp S6
A15/--- DI1 alarm
A16/--- DI2 alarm
A45/--- Standby mode
A59/--- Case clean
A97/--- Comp. Safety
AA3/--- High brine temp.
E1/--- Ctrl. error
E6/--- RTC error
E25/--- S3 error
E26/--- S4 error
E27/--- S5 error
E28/--- S6 error
E50/--- S7 error
--- Max Def.Time
Data communication
The importance of individual alarms can be defined with a setting. The setting must be carried out in the group "Alarm destinations"
Settings from
System manager AK-SM 720
High
Middle
Low
Log only
Disabled
20 | BC230086440483en-000201
Description
High temperature alarm
Low temperature alarm
Door alarm
The "o16" function is activated during a coordinated defrost
Temperature alarm. High S6
Temperature alarm. Low S6
DI1 alarm
DI2 alarm
Standby position (stopped refrigeration via r12 or DI input)
Case cleaning. Signal from DI input
Compressor safety. Signal from DI3 input is interrupted
High brine temperature alarm
Faults in the controller
Check clock
Error on S3 sensor
Error on S4 sensor
Error on S5 sensor
Error on S6 sensor
Error on S7 sensor
Defrost stopped based on time instead of, as wanted, on temperature
Settings from Send via
AKM (AKM destination) Network
1
2
3
X
X
X
Alarm relay groups
(P41)
1
2
8
16
1
2
8
8
-
-
8
8
32
32
4
4
4
4
4
16
(not in AK-SM 800 serie)
