User Guide | Controller for SemiPlugin appliance, AK-CC 460
Status on relay for cooling
Status on relay for fan
Status on relay for defrost
Status on relay for railheat
Status on relay for alarm
Status on relay for light
Status on relay for compressor 2
Readout of the actual rail heat effect in %
Readout of which thermostat used for regulation: 1= Thermostat 1,
2= Thermostat 2
Status on input DI3 (on/1 = 230 V)
Readout of the actual cutin value for the thermostat
Readout of the actual cut out value for the thermostat
Temperature measured by S7 brine sensor
Readout of the voltage signal on the analogue output
Forced control
If you need to force-control an output, you should set r12 to -1 (manual mode). You should then select the relevant relay function, e.g. u58. Go
to the function by pressing the middle button. Select On.
18 | BC230086440483en-000201
u58 Comp1/LLSV
u59 Fan relay
u60 Def. relay
u61 Railh. relay
u62 Alarm relay
u63 Light relay
u67 Comp2 relay
u85 Rail DutyC %
u86 Ther. band
u87 DI3 status
u90 Cutin temp.
u91 Cutout temp.
u98 S7 temp.
U44 AO_1 Volt
