User Guide | Controller for SemiPlugin appliance, AK-CC 460
Operating status
The controller goes through some regulating situations where it is just waiting for the next
point of the regulation. To make these "why is nothing happening" situations visible, you
can see an operating status on the display. Push briefly (1s) the upper button. If there is a
status code, it will be shown on the display. The individual status codes have the following
meanings:
Normal regulation
Waiting for end of the coordinated defrost
When the compressor is operating it must run for at least x minutes.
When the compressor is stopped, it must remain stopped for at least x minutes.
The evaporator drips off and waits for the time to run out
Refrigeration stopped by main switch. Either with r12 or a DI-input
Refrigeration stopped by thermostat
Refrigeration has been stopped by the S4 limit
Defrost sequence. Defrost in progress
Defrost sequence. Fan delay — water attaches to the evaporator
Door is open. DI input is open
Melt function in progress. Refrigeration is interrupted
Modulating thermostat control
Emergency cooling due to sensor error *)
Manual control of outputs
Case cleaning
Delay on outputs during start-up
Case shutdown
Other displays:
The defrost temperature cannot be displayed. There is stop based on time
Defrost in progress / First cooling after defrost
Password required. Set password
Regulation is stopped via main switch
*) Emergency cooling will take effect when there is lack of signal from a defined S3 or S4 sensor. The regulation will continue with a
registered average cutin frequency. There are two registered values – one for day operation and one for night operation.
© Danfoss | DCS (vt) | 2019.12
(Measurement)
Ctrl. state:
(Shown in all menu displays)
S0 0
S1 1
S2 2
S3 3
S4 4
S10 10
S11 11
S12 12
S14 14
S15 15
S17 17
S18 18
S19 19
S20 20
S25 25
S29 29
S32 32
S45 45
non
-d-
PS
OFF
