  • Page 1 MHP1335 MHP1544 Diesel Gas o line Bat tery Elec tric Bi-En ergy Op tions REPAIR PARTS MANUAL Part Num ber 13619-2 November 2012 (Rev B) Se rial Num ber MHP1335-07-000003 and after Ver sion 3...

  • Page 3: Table Of Contents

    Table of Contents Table of Contents General Specifications General Specifications MHP13/35 Mark II..i Battery ........x General Specifications MHP15/44 Mark II .
  • Page 4 Table of Contents Section 1. - Repair Parts Section 3. - Electrical Trailer assembly MHP13/35 ....1-3 Electrical schematic ......3-3 Trailer assembly MHP13/35 .

  • Page 5: General Specifications

    General Specifications The Snorkel MHP13/35 & MHP15/44 Mark II are boom supported elevating work platforms built to conform to these standards, American Standard ANSI A92.2 Australian Standard AS1418-10(Int) Elevating Work Platforms. General Specifications MHP13/35 Mark II SPECIFICATIONS MHP13/35 Mark II 12.6m...

  • Page 6: General Specifications Mhp15/44 Mark Ii

    Hydraulic system 4 independently operated hydraulic outriggers with safety Stabilisation interlocks 3.7 x 3.6m 12' 1" x 13' 9" Stabiliser footprint (max.) Snorkel orange base and covers, white turret and booms Standard colour 2.1m 6' 10" Transport height 7.45m 24' 5"...

  • Page 7: Engine Specifications

    Commissioning of the machine consists of performing the Pre Delivery and Inspection Report (PDIR) satisfactorily. This PDIR is performed by Snorkel or it's agent before the machine is delivered. A completed PDIR can be obtained, by request, from the salesagent.

  • Page 8: Working Envelope Mhp13/35 Mark Ii

    General Specifications Working Envelope MHP13/35 Mark II 42.6 39.3 32.8 29.5 26.2 22.9 19.6 16.4 13.1 METRES 13.1 13.1 16.4 19.6 22.9 FEET page iv Rev B MHP13/35 & MHP15/44 V3 – 13619-2...

  • Page 9: Stowed Unit Dimensions Mhp13/35 Mkii

    General Specifications Stowed Unit Dimensions MHP13/35 MKII 3.46m 5.99m (6.20m Includes optional rotator) 1.58m MHP13/35 & MHP15/44 V3 – 13619-2 Rev B page v...

  • Page 10: Working Envelope Mhp15/44 Mark Ii

    General Specifications Working Envelope MHP15/44 Mark II 52.5 49.2 45.9 42.6 39.3 32.8 29.5 26.2 22.9 19.6 16.4 13.1 METRES 16.4 13.1 13.1 16.4 19.6 22.9 26.2 FEET page vi Rev B MHP13/35 & MHP15/44 V3 – 13619-2...

  • Page 11: Stowed Unit Dimensions Mhp15/44 Mkii

    General Specifications Stowed Unit Dimensions MHP15/44 MKII 4.79m 7.45m (7.56m Includes optional rotator) 1.77m MHP13/35 & MHP15/44 V3 – 13619-2 Rev B page vii...

  • Page 13: 10.9M Height Restriction Kit

    10.9m Height Restriction Kit Introduction removed in the disabled position thus effectively 'locking' the machine into the restricted mode. MHP1544 units built for the Australian market may be fitted with a 10.9m height restriction kit. This kit is fitted to allow the maximum height to the platform floor to be restricted to10.9m from the ENABLED DISABLED...

  • Page 14: Tamper Protection

    10.9 Height Restriction unqualified person from operating the machine in the unrestricted mode. Tamper Protection In order to reduce the likelihood of the machine being tampered with to gain the extra height by an unqualified operator, a tamper protection device is installed on the machine.

  • Page 15: Maintenance Information

    Electrical (Section 3), contains listings and current production machines only. drawings of electrical components installations including wiring schematics. While Snorkel has attempted in every way to confirm that all information in this manual is correct, Options improvements are being constantly made to the machine that may not be reflected in this manual.

  • Page 16: Maintenance Schedules

    Maintenance schedules cylinder. Snorkel has established a Preventive Maintenance When raising a portion of the machine, be sure that Schedule that includes: adequate blocking is properly positioned - Do not Daily Maintenance (Operator’s Inspection)

  • Page 17: Daily Maintenance

    Pins and pin keepers Visually inspect (installation, condition) Hydraulic Hose Age Hoses used in Snorkel production units are manufactured by Hydraulink, Parker and Eaton and have a code stamped on them that offers the following information. Hydraulink Sample Hose Code...

  • Page 18: 90 Day Or 150 Hour Maintenance

    Maintenance Information 90 Day or 150 Hour Maintenance (Trained Service Technician) Components Service Required Recommended Lubricant or Further Instructions Daily maintenance Perform maintenance as per schedule Preventive inspection Perform inspection, complete form Retain copy of checklist maintenance checklist Placards and decals inspection Inspect using drawing and parts listing Replace any missing or in section 1 (repair parts)

  • Page 19: Lubricants

    Snorkel. repairs are needed. The engine MUST be operated in accordance with manufacturer’s instructions and Pressure gun application serviced at recommended intervals.

  • Page 20: Return Filter

    4. Lower the lower boom and raise the information. hydraulic legs. If questions still remain, contact Snorkel for further 5. Check the oil level as in information. 6. Lower stabiliser legs to operating position.
  • Page 21 Maintenance Information Lead-acid batteries contain sulfuric acid Lead-acid batteries produce flammable and which will damage eyes or skin on contact. explosive gases. NEVER allow smoking, When working around batteries, ALWAYS flames or sparks around batteries. wear a face shield to avoid acid in eyes. If acid contacts eyes, flush immediately with clear water and get medical attention.

  • Page 22: Preventive Inspection Maintenance

    Maintenance Information Preventive inspection maintenance 90 day or 150 hour checklist OK OK - No Service Required Serial Number Corrective Action Required Corrected, (Record description of corrective action). Check Inspection Procedures Codes Hydraulic hoses and tubes (3,5) Decals and placards (2,8) (1) Weld cracks, dents and/or rust Platform rotator (Optional) (3,4) (2) Installation...
  • Page 23 Maintenance Information Corrective Action Required Note: If correction action is required on any item, attach sheet indicating problem and action taken. All items have been properly checked and tested and found to be operating satisfactory or necessary corrective action has been completed. Inspected By: Date MHP13/35 &...

  • Page 24: Torque Chart

    Maintenance Information Torque chart PROPERTY CLASS 8.8 PROPERTY CLASS 10.9 TENSILE STRESS NOM SIZE TORQUE (N.m) TORQUE (N.m) CLAMP CLAMP AREA LOAD LOAD LUBED LUBED PITCH (mm ) k=0.20 k=0.15 k=0.20 k=0.15 x 0.5 5.03 2 200 1.32 0.99 2 990 1.79 1.34 M3.5 x 0.6...

  • Page 25: To Order Service Or Repair Parts

    Maintenance Information To order service or repair parts Manuals When placing an order for service or repair parts, Manuals are available from Snorkel to support any please have the following information available for of the machines that we produce. your machine.

  • Page 27: Stability Testing

    Stability Testing Stability Testing MHP13/35 The test procedure is as follows (Refer Figure 1). 1. Set a pulley with rope, 5.985m above the Introduction ground on a fixed pole. The purpose of this test is to assess if the MHP 2.
  • Page 28 Stability Testing Figure 1 ROPE CHAIN 70.1 M +W 7000 RATED LOAD R = 239kg MANUAL FORCE M = 44.8kg STANDARD MACHINE WIND FORCE W = 25.3kg = 217kg WITH ROTATOR LOAD ON PULLEY = 70.1kg page 18 Rev B MHP13/35 &...

  • Page 29: Stability Testing Mhp15/44

    Stability Testing The test procedure is as follows (Refer Figure 2). Stability Testing MHP15/44 1. Set a pulley with rope, 6.85m above the Introduction ground on a fixed pole. The purpose of this test is to assess if the MHP 2.
  • Page 30 Stability Testing Figure 1 ROPE CHAIN 72.2 M +W 8240 RATED LOAD R = 220kg MANUAL FORCE M = 45kg STANDARD MACHINE WIND FORCE W = 27.2kg = 194kg WITH ROTATOR LOAD ON PULLEY = 72.2kg page 20 Rev B MHP13/35 &...
  • Page 31 Section 1. - Repair Parts Section 1 Trailer assembly MHP13/35 ....1-3 Trailer assembly MHP13/35 ....1-4 Trailer assembly drawing MHP13/35 .
  • Page 32 page 1 - 2 Rev B MHP13/35 & MHP15/44 V3 – 13619-2...

  • Page 33: Trailer Assembly Mhp13/35

    Trailer assembly MHP13/35 Trailer assembly MHP13/35 Item Part No Description 12775 Trailer assembly 1273 Level bubble 1651 4 bank Casappa valve - (Not used when auto stabiliser option fitted) 1771-1 Lynch pin 3603-06 Plain washer 3603-08 Plain washer 3603-10 Plain washer 3603-12 Plain washer 3606-06025...

  • Page 34: Trailer Assembly Drawing Mhp13/35

    Trailer assembly MHP13/35 Trailer assembly MHP13/35 Item Part No Description 3610-20040 Bolt 12336A Leg cylinder assembly 12772-2 Tyre 3603-20 Plain washer 3611-20 Nylock nut 3626-5 Flanged bush 3626-1 Flanged bush 12439 Hose protector 3610-16100 Bolt (check thread length) 3604-06020 Screw 12703-3 U-bolt 12826...
  • Page 35 Trailer assembly drawing MHP13/35 TITLE Trailer Assembly Snorkel Model MHP13/35 V3 Page 1-5...
  • Page 36 Trailer assembly drawing MHP15/44 TITLE Trailer Assembly Snorkel Model MHP1544 V3 Page 1-6...

  • Page 37: Trailer Assembly Mhp15/44

    Trailer assembly MHP15/44 Trailer assembly MHP15/44 Item Part No Description 12777 Trailer assembly 1273 Level bubble 1651 4 bank Casappa valve - (Not used when auto stabiliser option fitted) 1771-1 Lynch pin 60030-061 Plain washer 3603-06 Plain washer 3603-08 Plain washer 3603-10 Plain washer 3603-12...
  • Page 38 Trailer assembly MHP15/44 Trailer assembly MHP15/44 Item Part No Description 45500-6 Key ring 60000-036 Roll pin 12336A Leg cylinder assembly 3603-20 Plain washer 3611-20 Nylock nut 3626-1 Flanged bush 3604-06020 Screw 12772-1 Wheel rim 3603-16 Plain washer 3611-16 Nylock nut 12703-3 U bolt 12826...

  • Page 40: Boom Assembly Mhp13/35

    Boom assembly MHP13/35 Boom assembly MHP13/35 Item Part No Description 12774 Boom assembly 1814 Nylon cable gland 3604-04040 Metric head pan screw 1771-1 Lynch pin 3606-06020 Countersunk screw 3610-10020 Metric bolt 3603-06 Plain washer 3626-1 Flanged bush 3626-10 Flanged bush 3626-13 Flanged bush 3626-5...
  • Page 41 Boom assembly drawing MHP13/35 TITLE Boom Assembly Page 1-11 Snorkel Model MHP13/35 V3...
  • Page 42 Boom assembly drawing MHP15/44 TITLE Boom Assembly Page 1-12 Snorkel Model MHP15/44 V3...

  • Page 43: Boom Assembly Mhp15/44

    Boom assembly MHP15/44 Boom assembly MHP15/44 Item Part No Description 12776 Boom assembly 1814 Nylon cable gland 3604-04040 Metric head pan screw 1771-1 Lynch pin 3606-06020 Countersunk screw 3610-10020 Metric bolt 3603-06 Plain washer 3626-1 Flanged bush 3626-10 Flanged bush 3626-13 Flanged bush 3626-5...

  • Page 44: Jib Boom Assembly

    Jib boom assembly Jib boom assembly Item Part No Description 12774 Jib boom assembly, MHP13/35 12776 Jib boom assembly, MHP15/44 3603-08 Washer, plain, M8 3610-06012 Bolt, metric, M6 x 12 3611-08 Nut, nyloc, M8 3617-16035 Bolt, metric 3626-1 Bush, flanged permaglide 3626-10 Bush, flanged permaglide 3626-13...
  • Page 45 Jib boom assembly drawing TITLE Jib Boom Assembly Snorkel Models Page 1-15 MHP13/35 & MHP15/44 V3...
  • Page 46 Column assembly drawing TITLE Column assembly Snorkel Models Page 1-16 MHP13/35 & MHP15/44 V3...

  • Page 47: Column Assembly

    Column assembly Column assembly Item Part No Description 12381A Column assembly 302-0049 Switch, battery disconnect, (24VDC option only) 1034-120 Washer, M16, galvanised, hardened 1067 Slew ring 1288 Battery 1808 PDL enclosure 1814 Cable gland 3566-1 Check valve, (24VDC & 230V option only) 3603-04 Washer, plain, M4 3603-05...
  • Page 48 Column assembly Column assembly Item Part No. Description 13632-10 Stay mount weld 13632-20 Cover stay weldment, (not shown) 60020-028N UNF hex bolt 60021-016 UNF nut 446086 Fuse block, (24VDC option only) 3087787 Contactor, 24V, sealed, (24VDC option only) 11430A Hydraulic oil tank assembly 12377A Main control manifold 12483A...

  • Page 50: Column Covers

    12401 Latch, compression 12403 Butt hinge 12414-20 Stay pivot mount 12414-5 Cover stay weldment 13632-20 Cover stay weldment from MHP1335-07-000005 onwards 12440 Tool clip 60038-006 Split pin 5510014 Latch, side cover page 1 - 20 Rev B MHP13/35 & MHP15/44 V3 – 13619-2...
  • Page 51 Column covers drawing TITLE Covers Snorkel Models Page 1-21 MHP13/35 & MHP15/44 V3...

  • Page 52: Fold Down Step Assembly

    Step assembly drawing TITLE Fold Down Step Assembly Snorkel Models Page 1-22 MHP13/35 & MHP15/44 V3...

  • Page 53: Step Assembly

    Step assembly Step assembly Item Part No Description 12480A Fold down step assembly 3603-08 Washer, plain, M8 3603-12 Washer, plain, M12 3610-08025 Bolt, metric, M6 x 25 3611-08 Nut, nyloc 3631-16 Washer, disc lock 11429-32 Bush 11429-34 Spring 13484 Basket weld 13514 Folding step weld 13563...

  • Page 54: Engine Assembly

    Engine assembly Engine assembly Item Part No Description 12413 Engine assembly 1171-4 Honda GX160 1171-4-022 Regulator / rectifier GX160 1171-4-025 Loom, Honda rectifier 1650-030 Battery cable 1650-031 Battery cable 1659 Gear pump 1880 Drive coupling 3602-06 Metric nut 3603-05 Plain washer 3603-06 Plain washer 3603-10...

  • Page 55: Engine Assembly Drawing

    Engine assembly drawing Engine assembly drawing DWG. 12413 MHP13/35 & MHP15/44 V3 – 13619-2 Rev B page 1 - 25...

  • Page 56: Basket Assembly

    Basket assembly Basket assembly Item Part No Description Basket assembly 3027 Flow control valve 3603-05 Washer, plain 3603-08 Washer, plain 3603-16 Washer, plain 3604-05012 Screw, Pan head, M5 x 12 3604-05020 Screw, machine 3605-05 Washer, spring 3608-16C Cone lok nut, M16 3610-05016 Bolt, metric 3610-05020...

  • Page 57: Basket Assembly Drawing

    Basket assembly drawing Basket assembly drawing MHP13/35 & MHP15/44 V3 – 13619-2 Rev B page 1 - 27...

  • Page 58: Tow Coupling Hydraulic

    Tow coupling hydraulic Tow coupling hydraulic Item Part No Description 11572 Coupling assembly, TC40HM/50mm 12780 Coupling assembly, (NZ only, 1 ") 11572-1 Body 11572-2 Main shaft and head assembly 9946-15 Main shaft spring 9946-13 Reverse lock 9946-14 Thrust ring 9946-17 Collar 60015-017 Grub screw 1 ¼”...

  • Page 59: Tow Coupling Hydraulic, Drawing

    Tow coupling hydraulic, drawing Tow coupling hydraulic, drawing MHP13/35 & MHP15/44 V3 – 13619-2 Rev B page 1 - 29...

  • Page 60: Placards And Decals Installation

    Placards and decals installation Placards and decals installation Item Part No Description 12833-2 Serial number plate 12814 Decal, hydraulic fluid 9751 Decal, NZ made 302950 Decal, hydraulic oil level 12424 Decal, towing speed 9207 Decal, hydraulic oil 9428 Decal, danger (Australia only) 1843 Decal, warning (New Zealand only) 511067-000...

  • Page 61: Placards And Decals Drawing

    Placards and decals drawing Placards and decals drawing 22 x 8 7 4 2 16 19 11 x 4 21 x 4 MHP13/35 & MHP15/44 V3 – 13619-2 Rev B page 1 - 31...

  • Page 62: 1750Kg Axle

    1750kg axle 1750kg axle Item Part No Description 12701 Axle assembly 11570-10 Wheel bearing kit (Includes 1,2,3,4) Wheel bearing Wheel bearing Wheel bearing 12362-1 Wheel hub 9297-7 Seal kit, hub 12362-2 1 Pair Brake pads 1033-008 Nut kit (Includes 10,11) Washer Split pin 9922-7...
  • Page 63 Axle assembly drawing See Pages 1-3 to 1-4 Trailer Assembly 1335 & Pages 1-6 to 1-8 Trailer Assembly 1544 for further details TITLE 1750kg Axle Assembly Hydraulic, Disc Brakes Page 1-33 Snorkel models MHP13/35 & 15/44 V3...

  • Page 65: Section 2. - Hydraulics

    Section 2. - Hydraulics Section 2 Hydraulic schematic drawing for standard units . . . 2-3 Hydraulic schematic drawing for units fitted with self level stabilisers ..2-4 Main control valve ......2-5 Upper lift cylinder assembly .
  • Page 66 page 2 - 2 Rev B MHP13/35 & MHP15/44 V3 – 13619-2...
  • Page 67 VALVE VALVE TANK STABILISER ACCUM TANK AUX. PORT PORT PORT MOTOR PUMP AUX. MOTOR OPTION RETURN FILTER 10 MICRON LEG 4 TITLE Hydraulic schematic for LEG VALVE BANK standard machines Snorkel Models MHP13/35 & MHP15/44 V3 Page 2-3 SEPT 2007...
  • Page 68 STABILISER ACCUM TANK AUX. PORT PORT PORT MOTOR PUMP AUX. MOTOR OPTION RETURN FILTER 10 MICRON LEG 4 LEG VALVE BANK 11921 TITLE Hydraulic schematic for units fitted with self level stabilisers Page 2-4 Snorkel Models MHP13/35 & MHP15/44 V3...

  • Page 69: Main Control Valve

    Main control valve Main control valve Item Part No Description 13712A Main control valve assembly 11415-1P Stabiliser solenoid 11415-2 Flow compensator 11415-3P Main relief valve 2500 psi 7035-003 Plug, 7/8" uno 11415-6P Check valve 4 psi 11415-77 Proportional flow control 11415-8P Control solenoid 11415-9P...

  • Page 70: Upper Lift Cylinder Assembly

    Upper lift cylinder assembly Upper lift cylinder assembly Item Part No Description 13710 Upper lift cylinder assembly 12333 Upper Lift cylinder 12333K Seal kit 3626-6 Flanged permaglide bush 7031-002 JICM x UN O-Ring M elbow 10856-1 Counterballance cartridge 13713 Plug 13705 Cartridge 7025-013...

  • Page 71: Lower Lift Cylinder Assembly

    Lower lift cylinder assembly Lower lift cylinder assembly Item Part No Description 13710 Lower lift cylinder assembly, MHP1335 12507A Lower lift cylinder assembly, MHP1544 12334 Cylinder, lower lift, MHP1335 12507 Cylinder, lower lift, MHP1544 12334K Seal kit, both models 3626-1...

  • Page 72: Flyboom Cylinder Assembly

    Flyboom cylinder assembly Flyboom cylinder assembly Item Part No Description 12332A Flyboom cylinder assembly 12332 Flyboom cylinder 12332K Seal kit 7031-002 JICM x UN O-Ring M elbow 10856-1 Counterbalance cartridge 10976-1 Cavity plug 3626-10 Flanged permaglide bush DWG. 12332A page 2 - 8 Rev B MHP13/35 &...

  • Page 73: Stabiliser Leg Cylinder Assembly

    Stabiliser leg cylinder assembly Stabiliser leg cylinder assembly Item Part No Description 12336A Stabiliser leg cylinder assembly 12336 Stabiliser leg cylinder 12336K Seal kit 3603-06 Plain washer 3663-04025 Hex head socket cap screw 3605-06 Spring washer 3610-06012 Metric bolt 3610-06020 Metric bolt 3611-04 Metric Nylock nut...

  • Page 74: Hydraulic Oil Tank Assembly

    Hydraulic oil tank assembly Hydraulic oil tank assembly Item Part No Description 14430A Hydraulic oil tank assembly 3603-06 Plain washer 3605-06 Spring washer 3611-06 Metric Nylock nut 3613-06030 Metric cap screw 7013-002 BSPP (Dowty) x JICM nipple 7034-004 0.5" BSPTM plug 11430-7 Suction pipe weldment (Replaces plug for electric motor option) 11430-10...

  • Page 75: Optional Rotator Cylinder Assembly

    Optional Rotator cylinder assembly Optional Rotator cylinder assembly Item Part No Description 12330A Rotator cylinder assembly 12330 Rotator cylinder 12330K Seal kit 3626-3 Flanged permaglide bush 7046-012 Elbow, BSPTM x JICM 7019-018 Nipple, BSPTM x JICM DWG. 12330A MHP13/35 & MHP15/44 V3 – 13619-2 Rev B page 2 - 11...

  • Page 76: Optional Oil Distributor Assembly - 2 Port

    Optional Oil distributor assembly - 2 port Optional Oil distributor assembly - 2 port Item Part No Description 12679A Oil distributor assembly, 2 port 3603-06 Plain washer 3605-06 Spring washer 3610-06020 Metric bolt 11957-3 Distributor cap 12679 Power plate rotator 12679-20 Spacer plate 60005-008...

  • Page 77: Optional Oil Distributor Assembly Drawing

    Optional Oil distributor assembly drawing Opti onal distr ibut or asse mbly draw MHP13/35 & MHP15/44 V3 – 13619-2 Rev B page 2 - 13...

  • Page 78: Optional Automatic Stabiliser

    Optional Automatic stabiliser Optional Automatic stabiliser Item Part No Description 11921A Manifold block assembly 11415-11 12V coil 11415-9 Valve spool 7034-001 Cavity Plug page 2 - 14 Rev B MHP13/35 & MHP15/44 V3 – 13619-2...

  • Page 79: Section 3. - Electrical

    Section 3. - Electrical Section 3 Electrical schematic ......3-3 Electrical schematic 240VAC option ......3-4 Automatic stabiliser control box assembly .
  • Page 81 Bleed Down Upper Cylinder Open = Height Exceeded P15-6 Bleed Down Lower Cylinder Tele Boom Key Lockout Closed = Lockout Disabled P15-7 Optional: Height Lockout P15-8 TITLE Electrical Schematic Upper Boom P15-11 P15-12 Page 3-3 Snorkel models MHP15/44 & MHP13/35 V3...

  • Page 82: 240Vac Option

    Open = Height Exceeded P15-6 Bleed Down Lower Cylinder Key Lockout Tele Boom Closed = Lockout Disabled P15-7 Optional Height Lockout TITLE Electrical Schematic - 240VAC Option P15-8 Upper Boom P15-11 Page 3-4 P15-12 Snorkel models MHP15/44 & MHP13/35 V3...

  • Page 83: Automatic Stabiliser Control Box Assembly

    Automatic stabiliser control box assembly Automatic stabiliser control box assembly Item Part No Description 13581 Control box assembly, auto stabiliser 12404 Control box 302-0018 Switch, toggle, DPDT (M/OFF/M) 12536-3 LED, 12V green 3604-05020 Screw, pan head M5 x 20 ZP 3605-05 Washer, spring, M5, ZP 3603-06...

  • Page 84: Upper Control Box Assembly

    Upper control box assembly Upper control box assembly Item Part No Description 13488A Upper control box assembly 13251-1 Control box 9775 Emergency stop switch, pull release 13380 Collar 10118 Contact, normally closed 3604-05020 Screw, pan head, M5 x 20 3605-05 Washer, spring, M5 3603-06 Washer, flat, M6 x 16...

  • Page 85: Lower Control Box Assembly

    Lower control box assembly Lower control box assembly Item Part No Description 13573A Lower control box assembly 12521-1 Control box, lower 12536-4 LED, 12V, red 13489-1 Knob, speed control 1814 Cable gland (not shown) 1815 Cable gland (not shown) 9775 Stop switch head 10744 Key switch...

  • Page 86: Ac Motor Option With 240Vac Outlet Drawing

    AC motor option with 240VAC outlet drawing AC motor option with 240VAC outlet drawing HONDA STARTER (terminal 85) SOLENOID SOCKET OUTLET CONTACTOR RELAY NEUTRAL PHASE LINE AC MOTOR SWITCH LOAD EARTH To B12 MOTOR To A8 12v.DC POWER SUPPLY page 3 - 8 Rev B MHP13/35 &...

  • Page 87: Wiring Diagram For Led Tail Lights

    Wiring diagram for LED tail lights Wiring diagram for LED tail lights NUMBER PLATE LIGHTS LEFT HAND RIGHT HAND TAIL LIGHT TAIL LIGHT WHITE WHITE WHITE/RED WHITE/RED PLUG CONNECTION UNDER PLATFORM FLOOR MALE FEMALE TRAILER PLUG WIRING CODE YELLOW - LH TURN - STOP BROWN - TAIL...

  • Page 89: Section 4. - Options

    Section 4. - Options Section 4 Engine assembly, Lombardini (Sheet 1) ..4-2 Engine assembly, Lombardini (Sheet 2) ..4-3 Basket rotator (Sheet 1) ..... 4-4 Basket rotator (Sheet 2) .

  • Page 90: Engine Assembly, Lombardini (Sheet 1)

    Engine assembly, Lombardini (Sheet 1) Engine assembly, Lombardini (Sheet 1) Item Part No Description 12449 Engine assembly 1171-8 Lombardini 15LD315 diesel engine 1650-030 Battery cable 1650-031 Battery cable 1657-11 Drive coupling 1659 Gear pump 3603-05 Plain washer 3603-08 Plain washer 3603-10 Plain washer 3605-06...

  • Page 91: Engine Assembly, Lombardini (Sheet 2)

    Engine assembly, Lombardini (Sheet 2) Engine assembly, Lombardini (Sheet 2) MHP13/35 & MHP15/44 V3 – 13619-2 Rev B page 4 - 3...

  • Page 92: Basket Rotator (Sheet 1)

    Basket rotator (Sheet 1) Basket rotator (Sheet 1) Item Part No Description 12441 Basket rotator assembly 8628 Pin keeper, rolled eye, 6mm 3610-06012 Bolt, M6 x 12 11492-1 Washer, tab 3617-16035 Bolt, metric 3631-16 Washer, disc lock 13468 Load cell 13497 Steel basket bottom mount 12330...
  • Page 93 Basket rotator (Sheet 2) TITLE Basket Rotator Assembly Sheet 2 Snorkel Models MHP13/35 & MHP15/44 V3 Page 4-5...

  • Page 94: Honda 240V Gas/Ac Option (Sheet 1)

    (See Options Section) POWER MOTOR ASSEMBLY SUPPLY UNIT (See Repair Parts Section) TRAILER ASSEMBLY ELECTRIC MOTOR SUPPLY BOX (See Repair Parts Section) (See Options Section) TITLE Honda 240V Gas/AC Option Sheet 1 Page 4-6 Snorkel Models MHP13/35 & MHP15/44 V3...

  • Page 95: Honda 240V Gas/Ac Option (Sheet 2)

    Honda 240V Gas/AC option (Sheet 2) Honda 240V Gas/AC option (Sheet 2) Item Part no Description 12436 Honda 240V Gas/AC option 3668-04016 Screw 3603-04 Plain washer 3611-04 Nylock nut 12779 Power supply unit 3603-10 Plain washer 3610-10045 Bolt 3611-10 Nylock nut 9018-5 240V AC motor assembly 3610-10055...

  • Page 96: Honda 240V Gas/Ac Option (Sheet 3)

    Honda 240V Gas/AC option (Sheet 3) Honda 240V Gas/AC option (Sheet 3) Item Part No Description 12486 Electric motor supply box 1815 Compression gland 1865-001 Switch 2500-5 Relay 2500-6 Relay mounting base 10967-1 10967-2 Appliance inlet 10967-4 Enclosure lid 10967-6 Enclosure 11588 Relay...

  • Page 97: Honda 240V Gas/Ac Option (Sheet 4)

    Honda 240V Gas/AC option (Sheet 4) Honda 240V Gas/AC option (Sheet 4) Item Part No Description 12436-1 Pump and motor assembly 1867-001 240V AC electric motor 1657-007 Coupling taper shaft 3612-06010 Grub screw 1658-006 Bell housing 11432 Pump 7013-004 BSPP x JICM nipple 3605-06 Spring washer 3610-06025...

  • Page 98: Ac Basket Outlet (Sheet 1)

    240V AC basket outlet (Sheet 1) 240V AC basket outlet (Sheet 1) Item Part No Description 12485-2 240V AC basket outlet assembly 1807 Appliance outlet 1865-001 Switch 10263 Compression gland 10967-3 Switch enclosure 10967-5 Mounting feet 3611-05 Nylock nut 3603-05 Plain washer 3610-05010 Bolt...

  • Page 99: Ac Basket Outlet (Sheet 2)

    240V AC basket outlet (Sheet 2) Basket Assembly ATTACHMENT DETAIL ATTACHMENT POSITION 240V AC BASKET OUTLET TITLE 240V AC Basket Outlet Sheet 2 Page 4-11 Snorkel Models MHP13/35 & MHP15/44 V3...
  • Page 100 240V AC Basket Outlet (Sheet 3) ATTACHMENT POSITION ATTACHMENT DETAIL GROUND POWER SUPPLY TITLE 240V AC Basket Outlet Sheet 3 Page 4-12 Snorkel Models MHP13/35 & MHP15/44 V3...

  • Page 101: Ac Basket Outlet (Sheet 4)

    240V AC basket outlet (Sheet 4) 240V AC basket outlet (Sheet 4) Item Part No Description 12485-1 Ground power supply inlet assembly 10263 Compression gland 10967-1 10967-2 Appliance inlet 10967-3 Enclosure 3603-05 Plain washer 3611-05 Nylock nut 3604-05020 Bolt MHP13/35 & MHP15/44 V3 – 13619-2 Rev B page 4 - 13...

  • Page 102: Bi-Energy Power Option (Sheet 1)

    Bi-Energy power option (Sheet 1) Bi-Energy power option (Sheet 1) Item Part No. Description 12413A Honda engine assembly 3566-1 Check valve 3603-10 Plain washer 3610-10065 Bolt 3611-10 Nylock nut 5560179 Washer, special 11946 Rubber boot 12434-10 Battery pad 12434A Pump assembly 24V DC 12705 24Volt master switch assembly 12706...

  • Page 103: Bi-Energy Power Option (Sheet 2)

    Bi-Energy power option (Sheet 2) TITLE Bi-Energy power option Sheet 2 Page 4-15 Snorkel Models MHP13/35 & MHP15/44 V3...

  • Page 104: Dc Electric Motor Option (Sheet 1)

    24V DC electric motor option (Sheet 1) TITLE 24V DC Electric Motor Option Sheet 1 Page 4-16 Snorkel Model MHP15/44 V3...

  • Page 105: Dc Electric Motor Option (Sheet 2)

    24V DC electric motor option (Sheet 2) 24V DC electric motor option (Sheet 2) Item Part No. Description 12434 24V DC Electric motor option 11946 Rubber boot 12434-10 Battery pad 12434A Pump assembly 24V DC 12705 24Volt master switch assembly 12706 Battery clamp 12706-11...

  • Page 106: Dc Electric Motor Option (Sheet 3)

    24V DC electric motor option (Sheet 3) 24V DC electric motor option (Sheet 3) Item Part No. Description 12188 Emergency pump assembly 3605-08 Spring washer 3605-10 Spring washer 3610-08020 Metric bolt 7025-001 Adaptor JICM - UNO 7025-003 Adaptor JICM - UNO 11930 Pump 3080046...

  • Page 107: Dc Electric Motor Option (Sheet 4)

    24V DC electric motor option (Sheet 4) 24V DC electric motor option (Sheet 4) Item Part No. Description 12705 Master switch assembly 302-0049 Battery disconnect switch 1814 Cable gland 10263 Compression gland 11408 Enclosure 3040671 Contator, 12 volt (not shown) 44607-6 Fuse (not shown) 11944...

  • Page 108: Continuous Rotation Option

    Continuous rotation option Continuous rotation option Item Part No Description 12443 Continuous rotation option 3610-08016 Bolt 3605-08 Spring washer 3603-08 Flat washer 12679-40 Moving bracket 12679A Oil distributor 3603-06 Flat washer 3605-06 Spring washer 3610-06020 Bolt COLUMN ASSEMBLY (See Repair Parts Section) OIL DISTRIBUTOR (See Hydraulics Section) TRAILER ASSEMBLY...

  • Page 109: Auto Stabiliser Option

    Auto stabiliser option Auto stabiliser option Item Part No Description 12433 Auto stabiliser option, Trionics 12418 Control lever guard 3602-10 3603-10 Plain washer 3611-10 Nylock nut 1273 Level bubble 12433-1 Control box, auto stabiliser 3603-05 Plain washer 3610-05012 Bolt 3610-06070 Bolt 3603-06 Plain washer...

  • Page 110: Flashing Light Option

    Flashing light option Flashing light option Item Part No Description 12488A Flashing light assembly 12488 Flashing light 3604-04020 Bolt 3605-04 Spring washer 3603-04 Plain washer ATTACHMENT POSITION ATTACHMENT DETAIL page 4 - 22 Rev B MHP13/35 & MHP15/44 V3 – 13619-2...

  • Page 111: 10.9 Metre Kit

    10.9 metre kit 10.9 metre kit Item Part No Description 12462 10.9 metre kit 3603-05 Plain washer 3605-12 Spring washer 3610-05020 Metric bolt 3611-05 Nyloc nut 3612-06006 Grub screw 12518 Cam, 10.9 metre option 12518-2 Bracket, 10.9 cam switch 12525 Limit switch Not shown is key switch - Refer to lower control box on page MHP13/35 &...
  • Page 113 Parts index - Page locator Oil capacity, A-iii Oil grade, A-iii 240V AC basket outlet, 4-10 Type, A-iii 240V AC electric motor assembly, 4-9 Flashing light assembly, 4-22 Auto stabiliser option, 4-21 Flyboom cylinder assembly, 2-8 Automatic stabiliser, 2-14 Fold down step assembly, 1-23 Automatic stabiliser control box assembly, 3-5 Axle assembly, 1750kg, 1-32 Ground power supply option, 4-13...
  • Page 114 © Snorkel – all rights reserved Printed in New Zealand...
  • Page 115 / loan / demonstration of the machine or delivery to an end user. 5) The Customer and Dealer shall not be entitled to the benefits of this warranty and Snorkel shall have no obligations here under unless the “Pre-Delivery and Inspection Report” has been properly completed and returned to the Snorkel Warranty department within ten (10) days after delivery of the Snorkel product to the Customer or Dealer’s demonstration / rental fleet.
  • Page 116 Confirmation that a qualified technician is available to replace the part and that t his person has been accepted by Snorkel to carry out such work under the warranty of the machine. Failure to do this may nullify the warranty.
  • Page 117 Snorkel Operation, Maintenance, and repair Parts Manuals. 4. Normal wear of any Snorkel component part(s). Normal wear of component parts may vary with the type, application or type of environment in which the machine may be used; such as, but not limited to sandblasting applications 5.
  • Page 118 Product Warranty APPEAL The buyer may appeal in writing against a rejected or adjusted claim to Snorkel warranty department within a period of 21 days of receiving the rejection or adjustment notice. The appeal should be grounded on express reasons and supported by relevant evidence. Appeals received outside of this time limit will not be considered.
  • Page 120 Local Distributor / Lokaler Vertiebshandler / Distributeur local El Distribuidor local / Il Distributore locale EUROPE, MIDDLE EAST AFRICA & ASIA PHONE: +44 (0) 845 1550 O57 FAX: +44 (0) 845 1557 756 NORTH & SOUTH AMERICA PHONE: +1 785 989 3000 TOLL FREE: +1 800 255 0317 FAX: +1 785 989 3070 AUSTRALIA...

This manual is also suitable for:

Mhp1544

Table of Contents
