CONNECTIONS
Front
A
3D Systems, Inc.
Direct Current Side
B
A

Positive Connection

B
Negative Connection
Positive Connection
401894 - Gray Wire
Main PCB Fan - Red Wire
Negative Connection
401884 - Green Wire and Yellow Wire
Main PCB Fan - Black Wire
401889-00 - Green Wire
