DEMO MANUAL DC1812A

parts list

ITEm QTy REFEREnCE
1 1 C2
2 1 C3
3 1 D1
4 1 D2
5 4 E1-E4
6 5 E5-E9
7 1 JP1
8 1 XJP1
9 1 J1
10 1 R
SENSE
11 3 R6, R7, R8
12 4 R2, R3, R4, R9
13 1 R5
14 1 S1
15 1 U2
16 1 FOR (J1)
17 1 U1
10
PART DESCRIPTIon
CAP., CHIP X7R, 0.1µF 0603
CAP., X7R, 1.0µF, 100V, 10%, 1206
LED, RED, LIGHT EMITTING DIODES
DIODE, BAT54C SOT23
TURRET, TESTPOINT .094"
TURRET, TESTPOINT .064"
HEADER, 3 PIN 1 ROW .079CC
SHUNT, .079" CENTER
HEADERS, VERTICAL DUAL 2×7 .079CC
RES., CHIP, 0.1Ω 1/8W 1% 1206
RES., CHIP, 4.99k, 1%, 0603
RES., CHIP, 10k, 5%, 0603
RES., CHIP, 1k, 5%, 0603
SWITCH, SMT PUSH BUTTON
I.C., SERIAL EEPROM TSSOP8
CABLE ASSY., 8" STRIP
I.C., BATTERY GAS GAUGE WITH I
mAnuFACTuRER/PART numBER
AVX, 06033C104KAT2A
MURATA, GRM31CR72A105KA01
PANASONIC, LN1251CTR
DIODES INC.,BAT54C-7-F
MILL-MAX, 2501-2-00-80-00-00-07-0
MILL-MAX, 2308-2-00-80-00-00-07-0
SAMTEC, TMM-103-02-L-S
SAMTEC, 2SN-BK-G
MOLEX, 87831-1420
IRC, LRC-LR1206LF-01-R100-F
NIC, NRC06J4991TRF
NIC, NRC06J103TRF
VISHAY, CRCW06031K00JNEA
PANASONIC, EVQPE105K
MICROCHIP, 24LC025-I/ST
LINEAR RIBBON CABLE CA-2440
2
C LINEAR TECH., LTC2943CDD
dc1812af
